Dahua DH-HAC-HFW1809T-A-LED 4K Full-color HDCVI Camera

Sale!
Dahua DH-HAC-HFW1809T-A-LED 4K Full-color HDCVI Camera
Dahua DH-HAC-HFW1809T-A-LED 4K Full-color HDCVI Camera - Image 2
Dahua DH-HAC-HFW1809T-A-LED 4K Full-color HDCVI Camera - Image 3
Dahua DH-HAC-HFW1809T-A-LED 4K Full-color HDCVI Camera - Image 4
Dahua DH-HAC-HFW1809T-A-LED 4K Full-color HDCVI Camera - Image 5

Price range: $89.99 through $109.99

SKU: N/A Category: Tags: , , , Brand:
📱 Contact via WhatsApp

Description

Dahua DH-HAC-HFW1809T-A-LED new-products  3.6mm DH-HAC- HFW1509T-A-LED 2.8mm DH-HAC-hfw1509t-a-led 3.6mm camera



HFW1809T-A-LED 4K Full-color HDCVI Fixed-focal Bullet Camera

> * The parameters and datasheets below can only be applied to 1809-S2 series.

> Max. 15 fps@4K.

> 3D NR.

> 24/7 color imaging.

> Smart Warm Light Illumination.

> 30 m illumination distance.

> Super Adapt.

> Built-in MIC.

> 3.6 mm fixed lens (2.8 mm optional).

> CVI/CVBS/AHD/TVI switchable.

IP67, 12 VDC.

Camera

Image Sensor

4K CMOS

Max. Resolution

3840 (H) × 2160 (V)

Electronic Shutter Speed

PAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100,000 s

Min. Illumination

0.0005 [email protected] (Color, 30 IRE)
0.00005 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on)

S/N Ratio

>65 dB

Illumination Distance

Warm light: 30 m (98.43 ft)

Illuminator On/Off Control

Auto/Manual

Illuminator Number

2 (Warm light)

Angle Adjustment

Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Lens Mount

M12

Focal Length

2.8 mm; 3.6 mm

Max. Aperture

F1.0

Field of View

2.8 mm: H: 109.6°; V: 57.5°; D: 131°
3.6 mm: H: 88.2°; V: 47.6°; D: 104.5°

Close Focus Distance

2.8 mm: 2.0 m (6.56 ft)
3.6 mm: 2.7 m (8.86 ft)

DORI Distance
Lens Detect Observe Recognize Identify
2.8 mm 88.0 m
( 288.71 ft)		 35.2 m
( 115.49 ft)		 17.6 m
( 57.74 ft)		 8.8 m

( 28.87 ft)
3.6 mm 104.0 m
( 341.21 ft)		 41.6 m
( 136.48 ft)		 20.8 m
( 68.24 ft)		 10.4 m

( 34.12 ft)
*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

ABF

Yes

Video

Video Frame Rate

CVI:
PAL: 4K@15 fps
NTSC: 4K@15 fps
AHD:
PAL: 4K@15 fps
NTSC: 4K@15 fps
TVI:
PAL: 4K@15 fps
NTSC: 4K@15 fps
CVBS:
PAL: 960H
NTSC: 960H

Resolution

4K (3840 × 2160); 960H (960 × 576/960 × 480)

Day/Night

Color

BLC

BLC; HLC; WDR

WDR

WDR

White Balance

Auto

Gain Control

Auto/Manual

Noise Reduction

3D NR

Illumination Mode

Smart Light

Mirror

Yes

Certification

Certifications

CE-LVD: EN 62368-1
CE-EMC: EN 55032; EN 55035

Audio

Built-in Mic

Yes

Camera Audio

CVI; TVI

Pick-up Distance

8 m (26.25 ft)

Port

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)

Power

Power Supply

12 VDC (±30%)

Power Consumption

Max 5.02 W (12 VDC, LED on)

Environment

Operating Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity

<95% (RH), non-condensing

Storage Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Storage Humidity

<95% (RH), non-condensing

Protection

IP67

Anti-corrosion Level

Basic Protection
*The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection.

Structure

Casing Material

Metal

Product Dimensions

174.2 mm × 70.6 mm × 72.3 mm (6.86″ × 2.78″ × 2.85″) (L × W × H)

Net Weight

0.39 kg (0.86 lb)

Gross Weight

0.48 kg (1.06 lb)

Installation

Wall mount; ceiling mount; vertical pole mount

Additional information

Lens

2.8mm, 3.6mm
Models

DH-HAC- HFW1509T-A-LED, DH-HAC- HFW1809T-A-LED
