Name: Dahua DH-HAC-HFW2802CM-A 4K Starlight HDCVI Camera
SKU: 51563
Availability: InStock

Sale!

Dahua DH-HAC-HFW2802CM-A 4K Starlight HDCVI Camera

Dahua DH-HAC-HFW2802CM-A 4K Starlight HDCVI Camera - Image 2

Original price was: $139.00.Current price is: $129.99.

Category: Secuity Camera Tags: DH-HAC-HFW2802CM-A, HAC-HFW2802CM-A

📱 Contact via WhatsApp

Description

Dahua DH-HAC-HFW2802CM-A 4K Starlight HDCVI Fixed-focal Bullet Camera

* The parameters and datasheets below can only be applied to 2802-S2 series.

> Max. 15 fps@4K.

> Starlight, 120 dB true WDR, 3D NR.

> Smart IR Illumination.

> 30 m illumination distance.

> Super Adapt.

> Built-in MIC.

> 3.6 mm fixed lens.

> CVI/CVBS/AHD/TVI switchable.

IP67, 12 VDC.

Camera

Image Sensor

4K CMOS

Max. Resolution

3840 (H) × 2160 (V)

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/3 s–1/100000 s
NTSC: 1/4 s–1/100000 s

Min. Illumination

0.001 [email protected] (Color, 30 IRE)
0.0001 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on)

S/N Ratio

>65 dB

Illumination Distance

30 m (98.43 ft)

Illuminator On/Off Control

Auto

Illuminator Number

3 (IR light)

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Auto Focus

Lens Mount

M12

Focal Length

3.6 mm

Max. Aperture

F1.5

Field of View

3.6mm: H: 87°; V: 49°; D: 99°

Iris Control

Fixed

Close Focus Distance

3.6 mm: 2.2 m (7.22 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

3.6 mm

98.0 m

(321.52 ft)

39.2 m

(128.61 ft)

19.6 m

(64.30 ft)

9.8 m

(32.15 ft)

DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video

Video Frame Rate

CVI: PAL: 4K@15 fps; 5 M@25 fps; 4M@25 fps
NTSC: 4K@15 fps; 5M@25 fps; 4M@30 fps
AHD: PAL: 4K@15 fps; NTSC: 4K@15 fps
TVI: PAL: 4K@15 fps; NTSC: 4K@15 fps
CVBS: PAL: 960H; NTSC: 960H

Resolution

4K (3840 × 2160); 5M (2880 × 1620); 4M (2560 × 1440); 960H (960 × 576/960 × 480)

Day/Night

Auto(ICR)/Color/B/W

BLC

BLC; HLC; WDR; HLC-Pro

WDR

120 dB

White Balance

Auto;Area white balance

Gain Control

Auto/Manual
