Dahua DHI-NVR616-64/128-4KS2 NVR5032/5064-4KS2 Network Video Recorder

Description

Dahua DHI-NVR616-64/128-4KS2 64/128 Channel Ultra 4K H.265 Network Video Recorder / NVR5032/5064-4KS2 32/64 Channel 3U 16HDDs 4K & H.265 Pro Network Video Recorder /DH-NVR5032FG-4KS2

DHI-NVR616-64/128-4KS2
64/128 Channel Ultra 4K H.265 Network Video Recorder

· Intel Processor
· Max 64/128 IP Camera Inputs
· Max 384Mbps Incoming Bandwidth
· Up to 12MP Resolution for Preview and Playback
· Supports RAID 0/1/5/10
· iSCSI and Mini SAS for Expanded Storage Space
· Smart Tracking and Intelligent Video

System Overview
Dahua’s next generation network video recorder offers unparalleled
recording technology for IP video surveillance applications. For
applications where details are critical for identification, this
enterprise-level NVR provides a powerful Intel processor with up to 4K
resolution. Additionally, the NVR features a mouse shortcut operation
menu, remote management and control, centre storage, edge storage,
and back up storage.
People Counting
Missing
Abandon Detection
4K Resolution
The NVR supports 4K ultra HD resolution (3840 x 2160) for recording, live
viewing and playback.
This NVR is ideal for a wide range of applications such as public safety,
transportation stations, government institutions, hotel resorts, shopping
malls, city centers, and financial institutions, where demand expansion
f
lexibility, high reliability and centralized storage management.
The NVR is compatible with numerous third-party devices making it
the perfect solution for surveillance systems with or without a video
management system (VMS). Its open architecture supports multi-user
access and is compatible with ONVIF 2.4, enabling interoperability when
combined with 4K cameras.
Functions
RAID 0/1/5/10
Offering a balance between storage performance, storage capacity,
and data integrity, the NVR features Fruitfull RAID 0/1/5/10 for faster and
safer recording.
Fisheye Dewarping
The NVR features multiple fisheye dewarping modes to make viewing
video easy whether its live or during playback.
N+M Hot Standby
The highly reliable redundancy N+M Hot Standby design provides a
secure, failover technique ensuring immediate backup. In the event of a
system failure, the slave instantly takes over the master ensuring no data
is lost.
Intelligent Video System (IVS)
With built-in intelligent video analytics, the NVR has the ability to detect
and analyze moving objects for improved video surveillance. The NVR
provides optional standard intelligence at the edge allowing detection
of multiple object behaviors such as abandoned or missing objects. IVS
also supports Tripwire analytics, allowing the camera to detect when
a pre-determined line has been crossed, People Counting, ideal for
business intelligence, and Facial Detection, for searching or identification
of individuals.
Heat Map
The NVR’s Heat Map option highlights the areas with the highest
concentration of people. This information can then be exported into a
customized report to assist in business or forensic analysis.
Point of Sale (POS)
Ideal for grocery and retail stores, the optional POS solution allows the
NVR to receive a POS transaction via corresponding video. This feature
allows merchants to analyze specific transactions via the Fuzzy search
Algorithm.
Smart Tracking
The auto tracking PTZ feature automatically tracks a moving target
throughout the camera’s field of view. This function is ideal for following
an object as it moves through airports, parking lots, city centers, or other
applications.
ANR (Automatic Network Replenishment Technology)
Video record in SD card in IP cameras when the network breaks down,
and after the network recovered, the video will be transferred to NVR
and then recorded in it

Technical Specification
System
Main Processor Intel Quad-core Processor
Operating System Embedded LINUX
Audio and Video
IP Camera Input 64/128 Channel
Two-way Talk 1 Channel Input, 1 Channel Output, RCA
Display
Interface 2 HDMI (up to 3840 x 2160 , Different Source),
1 VGA
Resolution 3840 × 2160 , 1920 × 1080 , 1280 × 1024,
1280 × 720 , 1024 × 768
Multi-screen Display 1st Screen: 1/4/8/9/16/25/36
2nd Screen: 1/4/8/9/16
OSD Camera title, Time, Video loss, Camera lock, Motion
detection, Recording
Recording
Compression H.265/H.264/MJPEG
Resolution 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP,
720P etc.
Record Rate 384Mbps
Bit Rate 16Kbps ~ 20Mbps Per Channel
Record Mode Manual, Schedule (Regular, MD (Motion Detection),
Alarm, IVS), Holiday, Stop
Record Interval 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30
sec, Post-record: 10 ~ 300 sec
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email,
FTP, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video
Loss and Tampering
Alarm input 16 Channel, Low Level Effective, Green Terminal
Interface
Relay Output 8 Channel, NO/NC Programmable, Green Terminal
Interface
Tracking Trigger Event Zoom, Tracking, Recording, Preset, Snapshot, Alarm,
etc.
Playback and Backup
Playback 128 Mbps in Raid 5 Mode;
64 Mbps in single HDD Mode
Search Mode Time /Date, Alarm, MD and Exact Search (accurate
to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next
File, Previous File, Next Camera, Previous Camera,
Full Screen, Repeat, Shuffle, Backup Selection,
Digital Zoom
Backup Mode USB Device/Network/eSATA Device
Third-party Support
Third-party Support
Dahua, Arecont Vision, AXIS, Bosch, Brickcom,
Canon, CP Plus, Dynacolor, Honeywell, Panasonic,
Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek,
and more

Network
Interface 4 RJ-45 Ports (10/100/1000Mbps)
Ethernet Port 4 Ethernet Ports Joint Working or 4 Independent
1000Mbps Ethernet Ports
PoE N/A
Network Function
HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP,
SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP,
Alarm Server, IP Search (Support Dahua IP camera,
DVR, NVS, etc.)
Optical Fiber Interface 2 Giga Optical Fiber Interface
Max. User Access 128 users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 2.4, CGI Conformant
Storage
Internal HDD 16 SATA III Ports, Up to 8 TB capacity for each HDD
HDD Mode Single, Raid 0/1/5/10(Enterprise-level HDDs are
recommended), Support Global HDD Hot-spare
eSATA 1 eSATA Port (Please contact technical engineer to
confirm the compatible device)
SAS 1 Mini SAS Port, for Storage Expansion
Auxiliary Interface
Front Cover Support Hot-swap
USB 4 USB Ports (2 USB 2.0 , 2 USB 3.0 )
RS232 1 Port, for PC Communication and Keyboard
RS485 1 Port, for PTZ Control
Electrical
Power Supply AC100V ~ 240V, 50 ~ 60 Hz
Power Consumption <51W (Without HDD)
Environmental
Operating Conditions-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
Dimensions 3U, 485mm x 512.9mm x 133.2mm (19.1″ x 20.2″
x 5.2″)
Net Weight 17.6kg (38.8 lb) (without HDD)
Gross Weight 27kg (59.5 lb)
Installation Rack-mounted
Certifications
CE EN55022, EN55024, EN50130-4, EN60950-1
FCC Part 15 Subpart B, ANSI C63.4-2014
UL UL 60950-1 and CAN/CSA C22.2 No.60950-1

NVR5032/5064-4KS2(only for project)

32/64 Channel 3U 16HDDs 4K & H.265 Pro Network Video Recorder
