Dahua TPC-DF1241-S8 (TPC-DF1241-B2F2-DW-S8)Thermal Network Mini Hybrid Eyeball Camera

Dahua TPC-DF1241-S8 (TPC-DF1241-B2F2-DW-S8)Thermal Network Mini Hybrid Eyeball Camera - DAHUA TPC-DF1241-B2F2-DW-S8, DAHUA TPC-DF1241-B2F2-DW-S8 CAMERA, DAHUA TPC-DF1241-S8, DAHUA TPC-DF1241-S8 CAMERA, default, df1241, fps, stream, TPC-DF1241-B2F2-DW-S8, TPC-DF1241-B2F2-DW-S8 CAMERA, TPC-DF1241-S8, TPC-DF1241-S8 CAMERA

$466.00

Category: Tags: , , , , , , , , , , ,
📱 Contact via WhatsApp

Description

TPC-DF1241-S8 (TPC-DF1241-B2F2-DW-S8)

Thermal Network Mini Hybrid Eyeball Camera

> Vanadium oxide uncooled focal plane detector.

> 4Megapixel progressive scan CMOS.

> AI functions: heat detection, tripwire, human/vehicle classification, smoking detection, and call detection.

> Built-in white light and audio alarm.

> Remote auxiliary management.

> Dual image fusion (visible and thermal channels).

> Wide input voltage 12 VDC ± 20%, and PoE.

IP67 rated.

Thermal
Detector Type Vanadium oxide uncooled focal plane detector
Max. Resolution 256 (H) × 192 (V)
Pixel Pitch 12 μm
Spectral Range

8 μm–14 μm
Thermal Sensitivity (NETD) < 40 mK (@f/1.0, 25 Hz, 300 K)
Field of View 2 mm: H: 87.8°; V: 63.8°
Close Focus Distance 2mm: 0.3 m (0.98 ft)
Detection Distance① 2 mm: Vehicle: 256 m (839.90 ft);

Human: 83 m (272.31 ft)
Recognition Distance② 2 mm: Vehicle: 63 m (206.69 ft);

Human: 21 m (68.90 ft)
Identification Distance③ 2 mm: Vehicle: 32 m (104.99 ft);

Human: 11 m (36.09 ft)
Note:

①Detection Distance: Detects objects, but cannot recognize their characteristics

(objects must cover more than 3.6 pixels of the image).

②Recognition Distance: Classifies objects into general categories, such as human,

vehicle (the object must cover more than 14 pixels of the image).

③Identification Distance: Classifies objects into specific categories based on their

characteristics, such as engineering truck, car (the object must cover more than 28

pixels of the image).
Aperture F1.0
Digital Detail
Enhancement (DDE)		 Yes
Digital Zoom 16 levels
AGC Auto; Manual
Noise Reduction 2D NR; 3D NR
Image Flip 180°
Color Palettes 18 (white hot/black hot/fusion/rainbow/golden autumn/midday/iron red/amber/jade/sunset/icefire/painting/pomegranate/emerald /spring/summer/autumn/winter)
Fusion Mode 3 (Warm color; Cool color; Ironred)
Visible
Image Sensor 1/2.7” CMOS
Max. Resolution 2336 (H) × 1752 (V)
Pixel 4 MP
Electronic Shutter Speed 1/30,000 s–1 s
Min. Illumination Color: 0.05 lux

Black & white: 0.005 lux

0 lux (IR on)
IR Illumination Distance 30 m (98.43 ft)
IR Illuminator On/Off Control Auto; Manual
Aperture 2 mm: F2.2
Field of View 2 mm: H: 94°; V: 72°
Focus Control Fixed
Close Focus Distance 2 mm: 0.3 m (0.98 ft)
Day/Night Auto (ICR); Color; B/W
BLC Yes
WDR DWDR
HLC Yes
White Balance Auto; Manual; Indoor; Outdoor; Tracking; Street lamp; Natural
AGC Auto; Manual
Noise Reduction 2D NR; 3D NR
S/N Ratio ≥55 dB
Region of Interest (RoI) Yes
Image Flip 180°
Exposure Compensation Yes
Intelligence
General Intelligence Tripwire; Intrusion
Advanced Intelligence Heat Detection & Alarm
Cold & Hot Spot Trace
Human & Vehicle Classification

Smoking Detection

Call Detection
Video and Audio
Video Compression H.265; H.264; H.264H; MJPEG
Resolution Thermal:

Main Stream: 1280 × 960 (1.3M); XVGA (1024 × 768);

VGA (640 × 480); 256 × 192; 1280 × 960 (by default)

Sub Stream: VGA (640 × 480); 256 × 192; 256 × 192 (by default)

Visual:

Main Stream: 2336 × 1752; 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576); 2336 × 1752 (by default)Sub Stream: 720p (1280 × 720); D1 (704 × 576); CIF (352 × 288); 352 × 288 (by default)
Frame Rate Thermal

50 Hz: (main stream) 1 fps–25 fps adjustable, 25 fps by default; (sub stream) 1 fps–25 fps adjustable, 15 fps by default

60 Hz: (main stream) 1 fps–30 fps adjustable, 30 fps by default; (sub stream) 1 fps–30 fps adjustable, 15 fps by default

Visual

50 Hz: (main stream) 1 fps–25 fps adjustable, 25 fps by default; (sub stream) 1 fps–25 fps adjustable, 15 fps by default

60 Hz: (main stream) 1 fps–30 fps adjustable, 30 fps by default; (sub stream) 1 fps–30 fps adjustable, 15 fps by default
Audio Compression G.711a; G.711mu; PCM
Network
Protocol HTTPS; HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP
Edge Storage Micro SD card (256 G)
Interoperability ONVIF; CGI; DaHua SDK
Browser IE: IE 8 and later

Google: 42 and earlier

Firefox: 42 and earlier
User/Host 10
Security Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access
Port
Network 1 × RJ-45 (10/100 Base-T)
Audio Input 1
Audio Output 1
Alarm Input 2
Alarm Output 2
RS-485 1 pair
Power
Power Supply 12 VDC, 1.2 A ± 20%; PoE
Power Consumption Basic: <3 W (12 VDC, LED off); 3.5 W (PoE)

Max: <7W (12 VDC, LED on, heater on); 9 W (PoE)
Environment
Operating Temperature –30 °C to +60 °C (–22 °F to +140 °F)
Storage Temperature –30 °C to +70 °C (–22 °F to ﹢158 °F)
Operating Humidity ≤95%
Protection IP67
Structure
Product Dimensions 122 mm × 122 mm × 112 mm (4.80″ × 4.80″ × 4.41″)

(L × W × H)
Packaging Dimensions 155 mm × 155 mm × 135 mm (6.10″ × 6.10″ × 5.31″)

(L × W × H)
Net Weight ≤0.85 kg (1.87 lb)
Gross Weight ≤1 kg (2.20 lb)
Heat Detection Distance
Focal Length Max. Distance
2 mm 25 m (82.02 ft)

Brand

Dahua
