DH-IPC-HDW2841T-ZS 8MP IR Vari-focal Eyeball WizSense Network Camera

Description

DH-IPC-HDW2841T-ZS 8MP IR Vari-focal Eyeball WizSense Network Camera
Launched by Dahua Technology, WizSense is a series of AI products and
solutions that adopt independent AI chip and deep learning algorithm.
It focuses on human and vehicle with high accuracy, enabling users to
fast act on defined targets. Based on Dahua’s advanced technologies,
WizSense provides intelligent, simple and inclusive products and
solutions.
System Overview
With advanced deep learning algorithm, Dahua WizSense 2 Series
network camera supports intelligent functions, such as perimeter
protection and smart motion detection. With starlight technology, this
series camera provides a better image effect in the condition of low
illuminance.
Functions
SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology
can categorize the targets that trigger motion detection and filter the
motion detection alarm triggered by non-concerned targets to realize
effective and accurate alarm.
· 8-MP 1/2.7″ CMOS image sensor, low luminance, and high definition
image.
· Outputs max. 8 MP (3840 × 2160)@20 fps and supports 2688 × 1520
(2688 × 1520)@25/30 fps.
· H.265 codec, high compression rate, ultra-low bit rate.
· Built-in IR LED, and the max. illumination distance is 40 m.
· ROI, SMART H.264+/H.265+, flexible coding, applicable to various
bandwidth and storage environments.
· Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable
to various monitoring scenes.
· Intelligent monitoring: Intrusion, tripwire (the two functions support the
classification and accurate detection of vehicle and human).
· Abnormality detection: Motion detection, video tampering, audio
detection, no SD card, SD card full, SD card error, network
disconnection, IP conflict, illegal access, and voltage detection.
· Supports max. 256 G Micro SD card; built in MIC.
· 12 VDC/PoE power supply, easy for installation.
· IP67 protection.
· SMD Plus.
WDR
With advanced Wide Dynamic Range (WDR) technology, Dahua network
camera provides clear details in the environment of strong brightness
contrast. The bright and dark area can get clear video even in high
brightness environment or with backlight shadow.
Smart H.265+ & Smart H.264+
With advanced scene-adaptive rate control algorithm, Dahua smart
encoding technology realizes the higher encoding efficiency than H.265
and H.264, provides high-quality video, and reduces the cost of storage
and transmission.
Perimeter Protection
With deep learning algorithm, Dahua Perimeter Protection technology
can recognize human and vehicle accurately. In restricted area (such
as pedestrian area and vehicle area), the false alarms of intelligent
detection based on target type (such as tripwire, intrusion) are largely
reduced.
Cyber Security
Dahua network cameras employ a series of security technologies,
including security authentication and authorization, access control
protocols, trusted protection, encrypted transmission and encrypted
storage. These technologies improve the camera’s defense against
external cyber threats and prevent malicious programs from
compromising the device.
Protection (IP67, Wide Voltage)
IP67: The camera passes a series of strict test on dust and soak. It has
dust-proof function, and the enclosure can work normally after soaking
in 1 m deep water for 30 minutes.
Wide voltage: The camera allows ±30% (for some power supplies)
input voltage tolerance (wide voltage range), and it is widely applied to
outdoor environment with instable voltage.

Technical Specification
Camera
Image Sensor 1/2.7″ CMOS
Max. Resolution 3840 (H) × 2160 (V)
ROM 128 MB
RAM 256 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.008 [email protected] (Color, 30 IRE)
0.0008 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio >56 dB
Illumination Distance 40 m (131.23 ft) (IR)
Illuminator On/Off Control Auto; Manual
Illuminator Number 2 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
Lens
Lens Type Motorized vari-focal
Lens Mount φ14
Focal Length 2.7 mm–13.5 mm
Max. Aperture F1.5
Field of View H: 113°–31°; V: 58°–18°; D: 138°–36°
Iris Control Fixed
Close Focus Distance 0.8 m (2.62 ft)
DORI
Distance
Lens Detect Observe Recognize Identify
W 85.3 m
(279.86 ft)
34.1 m
(111.88 ft)
17.1 m
(56.10 ft)
8.5 m
(27.89 ft)
T 280.0 m
(918.64 ft)
112.0 m
(367.45 ft)
56.0 m
(183.73 ft)
28.0 m
(97.86 ft)
Intelligence
IVS (Perimeter Protection)
Intrusion, tripwire (the two functions support the
classification and accurate detection of vehicle and
human)
Smart Search
Work together with Smart NVR to perform refine
intelligent search, event extraction and merging to event
videos
Video
Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported
by the sub stream)
Smart Codec Smart H.265+; Smart H.264+
Video Frame Rate
Main stream: 3840 × 2160@(1–20 fps)/2688 × 1520@
(1–25/30 fps)
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30
fps)
*The values above are the max. frame rates of each
stream; for multiple streams, the values will be subjected
to the total encoding capacity.
Stream Capability 2 streams
Resolution
3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048);
3072 × 1728 (3072 × 1728); 2880 × 1620 (2880 × 1620);
2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 ×
1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 ×
960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA
(640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night Auto(ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
White Balance Auto; natural; street lamp; outdoor; manual; regional
custom
Gain Control Auto;Manual
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Smart Illumination Yes
Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520
resolution and lower)
Mirror Yes
Privacy Masking 4 areas
Audio
Built-in MIC Yes
Audio Compression G.711a; G.711Mu; PCM; G.726
Alarm
Alarm Event
No SD card; SD card full; SD card error; network
disconnection; IP conflict; illegal access; motion
detection; video tampering; tripwire; intrusion; audio
detection; voltage detection; defocus detection; SMD;
security exception
Network
Network Port RJ-45 (10/100 Base-T)
SDK and API Yes
Network Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP;
SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP;
Multicast; ICMP; IGMP; NFS; PPPoE; Boujour
Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
User/Host 20 (Total bandwidth: 48 M)
Storage FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Browser IE; Chrome; Firefox
Management Software Smart PSS; DSS; DMSS
Mobile Client iOS; Android

DH-IPC-HDW2841T-ZS
Configuration encryption; trusted execution; Digest;
security logs; WSSE; account lockout; syslog; video
Cyber Security
Certification
Certifications
Power
Power Supply
Power Consumption
encryption; 802.1x; IP/MAC filtering; HTTPS; trusted
upgrade; trusted boot; firmware encryption; generation
and importing of X.509 certification
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
12 VDC/PoE (802.3af)
Ordering Information
Type
8MP Camera
Model
DH-IPC-HDW2841T-ZS
Basic: 2.8 W (12 VDC); 3.6 W (PoE)
Max. (H.265+ max. resolution + max. stream+ WDR + IR
intensity + IVS): 6.4 W (12 VDC); 7.6 W (PoE)
Environment
Operating Temperature–30 °C to +60 °C (–22 °F to +140 °F)
PFA130-E
PFB205W
PFA152-E
Accessories
(Optional)
Accessories
PFA106
PFB220C
PFM321D
PFM900-E
TF-P100
8MP IR Vari-focal Eyeball
WizSense Network Camera
Water-proof Junction Box
Wall Mount Bracket
Pole Mount Bracket
Mount Adapter
Ceiling Mount Bracket
12 VDC 1A Power Adapter
Integrated Mount Tester
MicroSD Memory Card
Operating Humidity
Storage Temperature
Storage Humidity
Protection
Structure
Casing Material
Product Dimensions
Net Weight
Gross Weight
≤95%–40 °C to +60 °C (–40 °F to +140 °F)
≤95%
IP67
Metal
108.3 mm × Φ122 mm (4.26″ × Φ4.80″)
0.70 kg (1.54 lb)
0.88 kg (1.94 lb)
Optional:
PFA130-E
Water-proof
Junction Box
PFA106
Mount
Adapter
PFM900-E
Integrated
Mount Tester
PFB205W
Wall Mount
Bracket
PFB220C
Ceiling Mount
Bracket
TF-P100
MicroSD
Memory Card
PFA152-E
Pole Mount
Bracket
PFM321D
12 VDC 1A
Power Adapter
