DH-IPC-HDW4631C-A 6MP HD POE IR IP Camera

Description

Dahua 6MP CCTV IP Camera DH-IPC-HDW4631C-A 2.8mm > 1/2.9” 6Megapixel progressive CMOS > H.265&H.264&MJPEG triple-stream encoding >20fps@6MP(3072×2048),25/30fps@4MP(2688×1520) > Smart detection supported > WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC > Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS > 2.8mm fixed lens > Built-in MiC > Max. IR LEDs Length 50m > PoE NVR4216-16P-4KS2 16  Channel 1U 16PoE 4K & H.265 Lite Network Video Recorder
> Smart H.265+/H.265/Smart H.264+/H.264
> Max 200Mbps Incoming Bandwidth
> Up to 8MP Resolution for Preview and Playback
> Up to 2ch@4K/8ch@1080P decoding
> HDMI/VGA simultaneous video output
> Support IPC UPnP, 16PoE ports Product Specifications System Main Processor Industrial embedded micro-processor Operating System Embedded Linux Operation Interface Web; local GUI Perimeter Protection by Camera Performance 16 channels AI Search Search for pictures by channel, time and event type SMD Plus by Camera Performance 16 channels AI Search Search by target classification (human, vehicle) Video Access Channel 16 Network Bandwidth 200 Mbps for access, 200 Mbps for storage and 96 Mbps for forwarding Resolution 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1.3MP, 720p, D1, and more Decoding Capability 8 channels@1080p (30 fps) Video Output HDMI: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720 VGA: 1920 × 1080; 1280 × 1024; 1280 × 720 Multi-screen Display 16-channel: 1/4/8/9/16 32-channel: 1/4/8/9/16/25/36 Third Party Camera Access Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon and more Compression Video Smart H.265+; Smart H.264+; H.265; H.264 Audio PCM; G.711A; G.711U; G.726 Network Network Protocol HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (supports Dahua IP camera, DVR, NVS, and more); P2P Mobile Phone Access Android; iOS Interoperability ONVIF (profile T/S/G); CGI; SDK Browser Chrome; IE9 or later; Firefox Record Playback Multi-channel Playback 1/4/9/16 Record Mode Manual; schedule (general; MD; alarm; MD & alarm; intelligent) Storage Method Local HDD and network Backup USB device Playback Function 1. Play; pause; stop; fast forward; fast backward; rewind; play by frame 2. Full screen; backup (cut/file) ; partially enlarge; audio on/off Storage Disk Group Yes Alarm General Alarm Motion detection; privacy masking; video loss; PIR alarm; IPC alarm Anomaly Alarm Camera offline; storage error; full storage; IP conflict; MAC conflict; login lock; network security anomaly Intelligent Alarm Perimeter protection; SMD; people counting; heat map Alarm Linkage Record; snapshot; IPC external alarm output; buzzer; log; preset; email External Port Audio Input 1 channel, RCA connector Audio Output 1 channel, RCA connector, which support voice intercom output HDD 2 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature Alarm Input 4 channels Alarm Output 2 channels USB 1 front USB 2.0 port, 1 rear USB 3.0 port HDMI 1 VGA 1 Network 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet port PoE 16 ports (IEEE802.3at/af) General Parameter Power Supply Single, 100V–240V AC, 50 Hz–60 Hz Power Consumption NVR: < 13.2W (without HDD) PoE: Max 25.5W for single port, 130W in total Net Weight 2.6 kg (5.7 lb) (without HDD) Gross Weight 4 kg (8.8 lb) (without HDD) Product Dimensions 375.0 mm × 327.4 mm × 53.0 mm (14.8″ × 12.9″ × 2.1″) Package Dimensions 429 mm × 360 mm × 137 mm (16.9″ × 14.2″ × 5.4″) Operating Temperature -10°C to +55°C (+14°F to +131°F) Storage Temperature 0°C to +40°C (+32°F to +104°F) Operating Humidity 10%–93% (RH) Storage Humidity 30%–85% (RH) Operating Altitude 3,000 m (9,843 ft) Certifications CE: EN55032; EN55024; EN50130-4; EN60950-1 FCC: Part 15 Subpart B; ANSI C63.4-2014 UL: UL 60950-1 Camera OEM IPC-HDW4631C-A 2.8MM Image Sensor 1/2.9” 6Megapixel progressive scan CMOS Effective Pixels 3072(H) x 2048(V) Scanning System Progressive Electronic Shutter Speed Auto/Manual, 1/3~1/100000s Minimum Illumination 0.002Lux( Color) 0.0002( black/white) 0Lux(IR on) S/N Ratio More than 56dB IR Distance Distance up to 30m IR On/Off Control Auto/ Manual IR LEDs 1 Lens Lens Type Fixed Mount Type Board-in Focal Length 2.8mm (3.6mm 6mm optional) Max. Aperture F2.5/F2.2/F2.0 Angle of View 2.8mm:H: 99° V: 69.4° 3.6mm:H: 70° V: 48° 6mm:H: 47.34° V: 33.75° Focus Control Fixed Close Focus Distance 0.8m (1.2m,3.9m) Intelligence IVS Tripwire, Intrusion, Object Abandoned/Missing Advanced Intelligent Functions Face Detection Video Compression H.265/H.264/MJPEG Streaming Capability 3 Streams Resolution 50HZ:Main (3072×2048@20fps),Sub(704×576@20fps),Third(1280×720@6fps); Main(2592×1944@25fps),Sub(704×576@25fps),Third(1280×720@4fps) 60Hz: Main(3072×2048@20fps),Sub(704×480@20fps),Third(1280×720@7fps); Main(2688×1520@30fps),Sub(704×480@30fps),Third(1280×720@10fps)” Bit Rate 14K ~ 10240Kbps Day/Night Auto(ICR) / Color / B/W BLC Mode BLC / HLC / WDR(120dB) White Balance Auto/Natural/Street Lamp/Outdoor/Manual Gain Control Auto/Manual Noise Reduction 3D DNR Motion Detetion Off / On (4 Zone, Rectangle) Region of Interest Off / On (4 Zone) Mirror Off / On Privacy Masking Off / On (4 Area, Rectangle) Audio Compression G.711a/ G.711Mu/ AAC/ G.726 Network Ethernet RJ-45 (10/100Base-T) Protocol HTTP; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; Dahua CP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP;NTP;IGMP; SNMP Interoperability ONVIF, PSIA, CGI;GB/T28181 Max. User Access 10 Users /20 Users Edge Storage NAS Local PC for instant recording Web Viewer IE, Chrome, Firefox, Safari Management Software Smart PSS, DSS, Easy4ip Smart Phone IOS, Android Interface Video Interface N/A Audio Interface Built-in Mic RS485 N/A Alarm N/A Electrical Power Supply DC12V, PoE (802.3af)(Class 0) Power Consumption <4.8W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Vandal Resistance N/A Construction Casing Metal Dimensions Φ106mm×93.7mm (4.17”×3.69”) Net Weight 0.47Kg (1.04lb) Gross Weight 0.65Kg (1.43lb)
