DH-IPC-HFW1239S1P-A 2 MP Entry Full-color Fixed-focal Bullet Network Camera

Sale!
DH-IPC-HFW1239S1P-A 2 MP Entry Full-color Fixed-focal Bullet Network Camera

Price range: $79.99 through $94.99

SKU: N/A Category: Tags: , , , , , Brand:
📱 Contact via WhatsApp

Description

DH-IPC-HFW1239S1P-A-LED-S4 DH-IPC-HFW1239S1P-A-IL DH-IPC-HFW1239S1-A-IL-S6 DH-HAC-HFW1239S1-A-LED DH-IPC-HFW1239S1P-A-LED DH-IPC-HFW1239S1-A-LED-S5

DH-IPC-HFW1239S1P-A-LED-S4  2 MP Entry Full-color Fixed-focal Bullet Network Camera

DH-IPC-HFW1239S1P-A-IL 2MP Entry Smart Dual Light Fixed-focal Bullet Network Camera

DH-IPC-HFW1239S1P-A-IL

2MP Entry Smart Dual Light Fixed-focal Bullet Network Camera

The parameters and datasheets below can only be applied to 1239-S6 series

• 2-MP 1/2.8″ CMOS image sensor, low luminance, and highdefinition image.

• Outputs max. 2 MP (1920 ×1080)@25/30 fps.

• H.265 codec, high compression rate, ultra-low bit rate.

• Built-in multi-core light, the max. IR distance is 30 m and the max.warm light distance is 30 m.

• DWDR, 3D NR, HLC, BLC, digital watermarking, applicable to variousmonitoring scenes.

• ROI, SMART H.264+/H.265+, flexible coding, applicable to variousbandwidth and storage environments.

• Abnormality detection: Motion detection, video tampering, audiodetection, network disconnection, IP conflict, illegal access.

• Built in Mic.

• 12 VDC/PoE power supply, easy for installation.

• IP67 protection.

• Supports human detection.

Camera

Image Sensor



1/2.8″ CMOS



Max. Resolution

1920 (H) × 1080 (V)

ROM

16 MB

RAM





64 MB





Scanning System



Progressive



Electronic Shutter Speed



Auto/Manual 1/3 s–1/100,000 s




Min. Illumination





0.005 [email protected] (Color, 30 IRE); 0.0005 [email protected] (B/W, 30 IRE);

0 lux (Illuminator on)




S/N Ratio





＞56 dB




Illumination Distance





Up to 30 m (98.43 ft) (IR)

Up to 30 m (98.43 ft) (Warm light)




Illuminator Number







1 (Multi-core (IR + warm) light)









Angle Adjustment





Pan: 0°–360°

Tilt: 0°–90°

Rotation: 0°–360°







Lens

Lens Type

Fixed-focal

Lens Mount

M12

Focal Length

2.8  mm; 3.6 mm

Max. Aperture

F1.6

Field of View



2.8 mm: H: 103°; V: 55°; D: 123° 3.6 mm: H: 87°; V: 44°; D: 105°



Iris Control

Fixed

Close Focus Distance





2.8 mm: 0.8 m (2.62 ft)

3.6 mm: 1.3 m (4.27 ft)







DORI Distance



*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.



Lens

Detect

Observe

Recognize

Identify


2.8 mm









44.1m( 144.69 ft)













17.7 m ( 58.07 ft)











8.8 m ( 28.87 ft)












4.4 m ( 14.44 ft)










3.6 mm





58.9m ( 193.24 ft)





23.6 m ( 77.43 ft)





11.8 m ( 38.71 ft)


5.9 m ( 19.36 ft)

Intelligence


Human Detection





Support the classification and accurate detection of human




Smart Search


Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos





Video


Video Compression





H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)




Smart Codec


Smart H.265+; Smart H.264+


Video Frame Rate





Main stream: 1920 × 1080@(1–25/30 fps)sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.




Stream Capability


2 Streams


Resolution





1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)




Bit Rate Control





VBR;CBR




Video Bit Rate





H.264: 32 kbps–4096 kbps;

H.265: 12 kbps–4096 kbps




Day/Night





Auto(ICR)/Color/B/W




BLC





Yes



HLC

Yes

WDR



DWDR




White Balance





Auto; natural; street lamp; outdoor; manual; regional custom




Gain Control





Auto/Manual




Noise Reduction





3D NR



Power


Motion Detection





OFF/ON (4 areas, rectangular)




Region of Interest (RoI)





Yes (4 areas)




Smart Illumination





Yes




Smart Dual Light





Yes




Image Rotation





0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)



Mirror

Yes







Privacy Masking





4 areas



Audio


Built-in MIC





Yes, built-in Mic




Audio Compression





G.711a; G.711Mu; PCM; G.726







Alarm


Alarm Event





Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception; SMD (human)







Network


Network Port





RJ-45 (10/100 Base-T)




SDK and API



Yes







Network Protocol





IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P




Interoperability


ONVIF (Profile S & Profile T); CGI


User/Host





6 (Total bandwidth: 24 M)




Storage


FTP


Browser





IE; Chrome; Firefox




Management Software





Smart PSS Lite; DSS; DMSS; DoLynk Care




Mobile Client





iOS;Android




Cyber Security





Video encryption;Configuration encryption;Digest;WSSE;Account lockout;Security logs;Generation and importing of X.509 certification;HTTPS;Trusted boot;Trusted execution;Trusted upgrade



Certification


Certifications





CE-LVD: EN62368-1;CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU







Power


Power Supply





12 VDC/PoE (802.3af)




Power Consumption





Basic: 1.4 W (12 VDC), 2.2 W (PoE);Max.: 3.3 W (12 VDC), 4.4 W (PoE) (H.265 + intelligence on + warm light intensity)

Environment

Operating Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity

≤95% (RH), non-condensing

Storage Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Storage Humidity

≤95% (RH), non-condensing

Protection

IP67

Structure

Casing Material

Inner core: Metal + Plastic; Cover: Plastic; Decoration ring: Plastic; Pedestal: Plastic

Product Dimensions

85.5 mm × Φ109 mm (3.37″ × Φ4.29″)

Net Weight

0.25 kg (0.55 lb)

Gross Weight

0.36 kg (0.79 lb)

DH-IPC-HFW1239S1P-A-LED-S4

2 MP Entry Full-color Fixed-focal Bullet Network Camera

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image

> H.265 codec, high compression rate, ultra-low bit rate

> Outputs max. 2 MP (1920 × 1080)@25/30 fps

> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access

> Built-in warm light, and the max. illumination distance is 15 m.

> 12V DC/PoE power support

> Built-in MIC

> IP67

Technical Specification

Camera

Image Sensor

1/2.8” 2Megapixel progresive CMOS

Effective Pixels

1920(H) x1080(V)

RAM/ROM

64MB/16MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

 0.005 [email protected]

S/N Ratio

More than 50dB

IR Distance

15 m (49.21 ft) (Warm light)

IR On/Off Control

Auto/ Manual

IR LEDs

1 (Warm light)

Lens

Lens Type

Fixed

Mount Type

M12

Focal Length

2.8 mm

3.6 mm

Max. Aperture

F1.6

Angle of View

H: 107°; V: 56°; D: 127°; H: 88°; V: 44°; D: 105°

Focus Control

Fixed

Close Focus Distance

0.7 m (2.30 ft); 1.3 m (4.27 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

43.9 m (144.0 ft)

17.5 m (57.4 ft)

8.8 m (28.9 ft)

4.4 m (14.4 ft)

3.6 mm

58.9 m (193.24 ft)

23.6 m (71.9 ft)

11.8 m (36.1 ft)

5.9 m (18.0ft)

PTZ

Pan/Tilt Range

Pan:0° ~360°; Tilt:0° ~90°; Rotation:0° ~360°

Video

Compression

H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)

Streaming Capability

2 Streams

Resolution

1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Frame Rate

Main stream: 1920 × 1080@1 fps–25/30 fps

Sub stream: 704 × 576@1 fps–25 fps 704 × 480@1 fps–30 fps

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 32 kbps–6144 kbps

H.265: 12 kbps–6144 kbps



Day/Night

Color/B/W

BLC Mode

BLC / HLC /DWDR





White Balance

Auto/Natural/Street Lamp/Outdoor/Manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Smart IR

Support

Digital Zoom

16x

Flip

0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)

Mirror

Yes

Privacy Masking

4 Areas

Audio & Alarm

Built-in MIC

Audio Compression

Alarm Event

Yes

G.711A; G.711Mu; G.726

Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP

Interoperability

ONVIF (Profile S); CGI; P2P; Genetec

Streaming Method

Unicast / Multicast

Max. User Access

6 (Total bandwidth: 36 M)

Edge Storage

FTP

Web Viewer

IE, Chrome, Firefox

Management Software

Smart PSS; DSS; DMSS

Smart Phone

IOS, Android

Certifications

Certifications

 CE-LVD: EN 62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B

Interface

Video Interface

N/A

Audio Interface

N/A

RS485

N/A

Alarm

N/A

Electrical

Power Supply

DC12V PoE (802.3af)

Power Consumption

Basic power consumption: 1.2 W (12 VDC); 2 W (PoE) Max. power consumption (H.265+Warm light intensity): 4.2 W (12 VDC); 5.4 W (PoE)





Environmental

Operating Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Strorage Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Construction

Casing

Metal+Plastic

Dimensions

 162.6 mm × 70 mm × 70 mm (6.40″ × 2.75″ × 2.75″) (L × W × H)

Net Weight

0.22 kg (0.49 lb)

Gross Weight

0.34 kg (0.75 lb)

Additional information

Lens

2.8mm, 3.6mm
Models

DH-IPC-HFW1239S1P-A-LED-S4, DH-IPC-HFW1239S1P-A-IL, DH-IPC-HFW1239S1-A-IL-S6, DH-HAC-HFW1239S1-A-LED, DH-IPC-HFW1239S1-A-LED-S5, DH-IPC-HFW1239S1P-A-LED

Brand

Dahua
