DH-IPC-MW4231A-E2 2MP Dual Lens Dash Camera

Description

DH-IPC-MW4231A-E2 2MP Dual Lens Dash Camera
· 1/2.8” 2Megapixel progressive scan STARVIS™ CMOS
· H.265&H.264 double-stream encoding
· 25/30fps@1080P(1920×1080)
· WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
· Multiple network monitoring: Web viewer, CMS(DSS/PSS) &
DMSS
· 2.1mm(Rear),2.8mm(Front) Fixed lens
· Micro SD memory
2Mp
H.265
Analysis
System Overview
Dahua Dual Lens dash camera is specially designed for taxi, online
car-hailing and other vehicles. The camera is equipped with two lens
which can meet the view requirement of both front and rear. Besides,
the device owns some smart technologies such as starlight, intelligent
image analysis and so on. With its intelligent functions, the device can
provide excellent image quality and efficient event reminders
Starlight
data compression ratio at the same level of video quality, or substantially
improved video quality at the same bit rate, as compared to older video
compression technologies. H.265 offers such impressive compression by
expanding the pattern comparison and difference-coding, improving
motion vector prediction and motion region merging, and incorporating
an additional filtering step called sample-adaptive offset filtering.
Functions
Starlight Technology
For challenging low-light applications, Dahua’s Starlight Ultra-low Light
Technology offers best-in-class light sensitivity, capturing color details
in low light down to 0.005lux. The camera uses a set of optical features
to balance light throughout the scene, resulting in clear images in dark
environments.
Wide Dynamic Range (WDR)
The camera achieves vivid images, even in the most intense contrast
lighting conditions, using industry-leading wide dynamic range (WDR)
technology. For applications with both bright and low lighting conditions
that change quickly, true WDR (120 dB) optimizes both the bright and
dark areas of a scene at the same time to provide usable video.
Intelligent Video analysis (IVS)
IVS is a built-in video analytic algorithm that delivers intelligent functions
to monitor a scene for Tripwire violations, intrusion detection, and
abandoned or missing objects. A camera with IVS quickly and accurately
responds to monitoring events in a specific area. In addition to scene
analytics, the camera supports face detection to quickly capture a
face and upload the image to a server. The camera also offers tamper
detection by recognizing a dramatic scene change and generating a
warning message to inspect the camera.
HEVC (H.265)
The H.265 (ITU-T VCEG) video compression standard offers double the

Mobile Series | DH-IPC-MW4231A-E2
Technical Specification
Camera
Image Sensor 1/2.8” 2Megapixel progressive scan CMOS
Effective Pixels 1920(H)x1080(V)
RAM/ROM 512MB/32MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3~1/100000s
Minimum Illumination
Front :
0.009Lux/F2.2( Color,1/3s,30IRE)
0.07Lux/2.2( Color,1/30s,30IRE)
0Lux/F2.2(B/W)
Rear :
0.009Lux/F2.0( Color,1/3s,30IRE)
0.07Lux/2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
S/N Ratio More than 50dB
IR Distance Distance up to 2m(6.56ft)
IR On/Off Control Auto/Manual
IR LEDs 1
Lens
Lens Type Fixed
Mount Type Board-in
Focal Length 2.1mm(Rear)/2.8mm(Front)
Max. Aperture F2.0(Rear)F2.2(Front)
Angle of View
Rear : H:133.6˚ V:78.4˚
Front : H:114.6˚ V:57.5˚
Optical Zoom N/A
Focus Control N/A
Predictive Focus Algorithm
(PFA) N/A
Close Focus Distance 0.5m(1.64ft)
DORI
Distance
Lens Detect Observe Recognize Identify
2.1mm 36.7m(120ft) 14.7m(48ft) 7.3m(24ft) 3.7m(12ft)
2.8mm 38.6m(127ft) 15.4m(51ft) 7.7m(25ft) 3.9m(13ft)
Pan/Tilt/Rotation
Pan/Tilt/Rotation Range Bracket :Pan:0˚~330˚; Tilt:-15˚-15˚
Rear Camera :Pan:15˚-15˚; Tilt:-15˚-15˚
Intelligence
Event Trigger Motion detection, Video tampering , Scene changing,
Illegal Access,Storage anomaly
IVS Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions Face Detection
Video
Compression H.265/H.264H/MJPEG(Sub Stream)
Smart Codec N/A
Streaming Capability 2X2 Streams
Resolution 1080P(1920×1080)/ 1.3M(1280×960)/ 720P(1280×720)/
D1(704×576/704×480) /CIF(352×288/342×240)
Frame Rate
Main Stream:
CH1: 1080P (1~25/30fps)
CH2: 1080P (1~25/30fps)
Sub Stream:
CH1: D1(1~25/30fps)
CH2: D1(1~25/30fps)

Bit Rate Control CBR/VBR
Bit Rate H.264: 32~ 10240Kbps H.265: 12~ 6400Kbps
Day/Night Rear : Auto(ICR) / Color / B/W
Front: Electronic
BLC Mode BLC / HLC / WDR(120dB)
White Balance Auto/Manual
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detection Off / On (4 Zone, Rectangle)
Region of Interest Off / On (4 Zone)
Electronic Image Stabilization
(EIS) N/A
Smart IR N/A
Defog N/A
Digital Zoom 16x
Flip 0°/90°/270°
Mirror Off / On
Privacy Masking Off / On (4 Area, Rectangle)
Audio
Compression G.711A/G.711Mu/G.726/AAC
Network
Ethernet M12 (10/100Base-T)
Protocol
HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;
FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;
NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;S
NMP;TLS
Interoperability ONVIF;CGI
Streaming Method Unicast / Multicast
Max. User Access 10Users/20Users
Edge Storage
NAS
FTP
Mirco SD card 128GB
Web Viewer IE, Chrome
Management Software Smart PSS, DSS, DMSS
Smart Phone IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface
Video Interface N/A
Audio Interface Built-in Mic
RS485 N/A
Alarm N/A
Mobile Series | DH-IPC-MW4231A-E2
Electrical
Power Supply
Power Consumption
Environmental
Operating Conditions
Strorage Conditions
Ingress Protection
Vandal Resistance
Construction
Casing
Dimensions
Net Weight
Gross Weight
Dimensions (mm/inch)
DC12V(±30%)
DC 12V: 4.4W 5.4W(IR on)
N/A
N/A-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Metal,Plastic
123mm×126mm×48.1mm (4.84”×4..96”×1.89”)
250g (0.55lb)
320g (0.71lb)
Ordering Information
Type
2MP camera
Part Number
DH-IPC
MW4231AP-E2
DH-IPC
MW4231AN-E2
Description
2MP Dual Lens Dash Camera,PAL
2MP Dual Lens Dash Camera,NTSC
IPC
MW4231AP-E2
IPC
MW4231AN-E2
M12 Connector
CN1
1
2
3
4
5
8
CN2
4
5
1
2
Function
ETHRX
ETHRX+
ETHTX
2MP Dual Lens Dash Camera,PAL
2MP Dual Lens Dash Camera,NTSC
Color
Blue
Orange
Purple
ETHTX+
6
3
CN2
GND
+12V
Brown
Black
Red
Wire Gauge
30AWG
30AWG
30AWG
30AWG
26AWG
26AWG
CN1
