DH-SD6CE230I-HC-S3 2MP 30x Starlight IR PTZ HDCVI Camera

Description

DH-SD6CE230I-HC-S3 2MP 30x Starlight IR PTZ HDCVI Camera
System Overview
Featuring powerful optical zoom and accurate pan/tilt/zoom
performance, this camera can provide large monitoring range and great
detail. The camera has very excellent low light performance due to
adopting the latest starlight technology. The camera is equipped with
smooth control, high quality image and good protection, which make it
can meet most of the requirements of video surveillance applications.
Functions
Simplicity
HDCVI technology inherits the born feature of simplicity from traditional
analog surveillance system, making itself a best choice for investment
protection. HDCVI system can seamlessly upgrade the traditional
analog system without replacing existing coaxial cabling. The plug and
play approach enables full HD video surveillance without the hassle of
configuring a network.
Starlight Technology
For challenging low-light applications, Dahua’s Starlight Ultra-low Light
Technology offers best-in-class light sensitivity, capturing color details
in low light down to 0.005lux. The camera uses a set of optical features
to balance light throughout the scene, resulting in clear images in dark
environments.
Wide Dynamic Range
The camera achieves vivid images, even in the most intense contrast
lighting conditions, using industry-leading wide dynamic range (WDR)
technology. For applications with both bright and low lighting conditions
that change quickly, True WDR (120 dB) optimizes both the bright and
dark areas of a scene at the same time to provide usable video.
· 1/2.8” 2Megapixel STARVIS™ CMOS
· Powerful 30x optical zoom
· Starlight technology
· 120dB true WDR, 3D DNR
· Max. 25/30fps@1080P
· IR distance up to 200m
· IP67, IK10
Environmental
Dahua cameras operate in extreme temperature environments, rated
for use in temperatures from -40°C ~ 70°C (-40°F ~ +158°F) with
95% humidity. The camera complies with the IK10 Vandal Resistance
impact rating. Subjected to rigorous dust and water immersion tests
and certified to the IP67 Ingress Protection rating makes it suitable for
demanding outdoor applications.
Protection
The camera allows for ±25% input voltage tolerance, suitable for the
unstable conditions for outdoor applications. Its 8KV lightning rating
provides effective protection for both the camera and its structure
against lightning.

Pro Series | DH-SD6CE230I-HC
Technical Specification
Camera
Image Sensor 1/2.8” STARVIS™ CMOS
Effective Pixels 1920(H) x 1080(V), 2 Megapixels
Scanning System Progressive
Electronic Shutter Speed 1/1s~1/30,000s
Minimum Illumination Color: [email protected]; B/W: [email protected];
[email protected] (IR on)
IR Distance Distance up to 200m (656ft)
IR On/Off Control Auto/Manual
IR LEDs 6
Lens
Focal Length 4.5mm~135mm
Max. Aperture F1.6 ~ F4.4
Angle of View H: 67.8° ~ 2.4°
Optical Zoom 30x
Focus Control Auto/Manual
Close Focus Distance 100mm~ 1000mm
DORI Distance
*Note: The DORI distance is a “general proximity” of distance which makes it easy to
pinpoint the right camera for your needs. The DORI distance is calculated based on
sensor specification and lab test result according to EN 62676-4 which defines the
criteria for Detect, Observe, Recognize and Identify respectively.
Detect Observe Recognize Identify
1862m(6109ft) 744m(2441ft) 372m(1220ft) 186m(610ft)
PTZ
Pan/Tilt Range Pan: 0° ~ 360° endless; Tilt: -20° ~ 90°,auto flip 180°
Manual Control Speed Pan: 0.1° ~200° /s; Tilt: 0.1° ~120° /s
Preset Speed Pan: 300° /s; Tilt: 200° /s
Presets 300
PTZ Mode 5 Pattern, 8 Tour, Auto Pan ,Auto Scan
Speed Setup Human-oriented focal Length/ speed adaptation
Power up Action Auto restore to previous PTZ and lens status after
power failure
Idle Motion Activate Preset/ Scan/ Tour/ Pattern if there is no
command in the specified period
Protocol DH-SD, Pelco-P/D (Auto recognition)

Video
Resolution 1080P(1920×1080) / 720P(1280×720)
Frame Rate 25/30fps@1080P, 25/30/50/60fps@720P
Video Output 1-channel BNC high definition video output/ CVBS
standard definition video output (switchable)
Day/Night Auto(ICR) / Color / B/W
OSD Menu Support
Backlight Compensation BLC / HLC / WDR (120dB)
White Balance Auto, ATW, Indoor, Outdoor, Manual
Gain Control Auto / Manual
Noise Reduction Ultra DNR (2D/3D)
Defog Support
Digital Zoom 16x
Flip 180°
Privacy Masking Up to 24 areas
Certifications
Certifications
CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB,ANSI C63.4- 2014
UL: UL60950-1+CAN/CSA C22.2,No.60950-1
Interface
Video Interface 1 port(BNC, 1.0V[p-p], 75Ω)
RS485 1
Audio Interface 1 channel in
Alarm I/O 2/1
Electrical
Power Supply AC24V/3A(±25%)
Power Consumption 24W, 38W(IR On, Heater On)
Environmental
Operating Conditions-40°C ~ 70°C (-40°F ~ +158°F) / Less than 95% RH
Ingress Protection IP67
Vandal Resistance IK10
Construction
Casing Metal
Dimensions φ209×337.4mm
Net Weight 5.8kg(12.79lb)
Gross Weight 9.6kg(21.16lb)

Pro Series | DH-SD6CE230I-HC
www.dahuasecurity.com
Ordering Information
Type Part Number Description
2MP PTZ
Camera
DH-SD6CE230I-HC 2MP 30x Starlight IR PTZ HDCVI
Camera, WDR, PAL
DH-SD6CE230IN-HC 2MP 30x Starlight IR PTZ HDCVI
Camera, WDR, NTSC
SD6CE230I-HC 2MP 30x Starlight IR PTZ HDCVI
Camera, WDR, PAL
SD6CE230IN-HC 2MP 30x Starlight IR PTZ HDCVI
Camera, WDR, NTSC
Accessories
PFB305W Wall Mount
AC24V/3A Power Adapter
PFA111 Mount Adapter
PFA140 Power Box
PFB300C Ceiling Mount
PFA120 Junction Box
PFA150 Pole Mount
PFA151 Corner Mount
PFB303S Parapet Mount
Included:
PFA140
Power Box
PFA150
Pole Mount
PFA120
Junction Box
PFB300C
Ceiling Mount
PFB303S
Parapet Mount
