Name: Hikvision DS-2CD2383G2-LI2U/S(L)(RB) 8 MP Acusense Strobe Light and Audible Warning &amp; Smart Hybrid Light Fixed Turret Network Camera
SKU: 38979
Availability: InStock

Hikvision DS-2CD2383G2-LI2U/S(L)(RB) 8 MP Acusense Strobe Light and Audible Warning & Smart Hybrid Light Fixed Turret Network Camera - 2cd2383g2, DS-2CD2383G2-LI2U/S(L)(RB), DS-2CD2383G2-LI2U/S(L)(RB) camera, fps, Hikvision DS-2CD2383G2-LI2U/S(L)(RB), Hikvision DS-2CD2383G2-LI2U/S(L)(RB) camera, li2u, light, stream

Price range: $195.99 through $199.99

Models

Color

Clear

SKU: N/A Category: Secuity Camera Tags: 2cd2383g2, DS-2CD2383G2-LI2U/S(L)(RB), DS-2CD2383G2-LI2U/S(L)(RB) camera, fps, Hikvision DS-2CD2383G2-LI2U/S(L)(RB), Hikvision DS-2CD2383G2-LI2U/S(L)(RB) camera, li2u, light, stream

📱 Contact via WhatsApp

Hikvision

Description

High quality imaging with 8 MP resolution
AcuSense: Focus on person and vehicle classification based on deep learning
Smart Hybrid Light: Integrates IR and White lights, 3 supplemental lighting modes
Built-in arrayed dual-microphone for real-time high quality audio security
Clear imaging against strong back light due to 120 dB true WDR technology
Efficient H.265+ compression technology
Water and dust resistant (IP67)
Active strobe light and audio alarm to warn intruders off

Available models:

DS-2CD2383G2-LI2U/SL(2.8mm)

DS-2CD2383G2-LI2U/SL(4mm)

DS-2CD2383G2-LI2U/SRB(2.8mm)

DS-2CD2383G2-LI2U/SRB(4mm)

Camera
Image Sensor1/2.8″ Progressive Scan CMOS
Max. Resolution3840 × 2160
Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON),0 Lux with light
Shutter Time1/3 s to 1/100,000 s
Day & NightIR cut filter
Angle AdjustmentPan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°

Lens
Lens TypeFixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 108°, vertical FOV 59°, diagonal FOV 127°

4 mm, horizontal FOV 88°, vertical FOV 44°, diagonal FOV 105°
Lens MountM12
Iris TypeFixed
ApertureF1.6
Depth of Field
2.8 mm: 1.7 m to ∞

4 mm: 2.6 m to ∞

DORI
DORI
2.8 mm, D: 84 m, O: 33 m, R: 16 m, I: 8 m

4 mm, D: 117 m, O: 46 m, R: 23 m, I: 11 m

Illuminator
Supplement Light TypeIR,White Light
Supplement Light RangeUp to 30 m
Smart Supplement LightYes
IR Wavelength850 nm

Video
Main Stream
50 Hz:

20 fps (3840 × 2160)

25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

60 Hz:

20 fps (3840 × 2160)

30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

*Third stream is supported under certain settings.
Video Compression
Main stream: H.265/H.264/H.264+/H.265+,

Sub-stream: H.265/H.264/MJPEG,

Third stream: H.265/H.264,

*Third stream is supported under certain settings.
Video Bit Rate32 Kbps to 16 Mbps
H.264 TypeBaseline Profile,Main Profile,High Profile
H.265 TypeMain Profile
Scalable Video Coding (SVC)H.264 and H.265 encoding
Bit Rate ControlCBR,VBR
Region of Interest (ROI)1 fixed region for main stream and sub-stream
Target CroppingYes

Audio
Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
Environment Noise FilteringYes

Network
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
Simultaneous Live ViewUp to 6 channels
APIONVIF (Profile S, Profile G),ISAPI,SDK,ISUP
SecurityPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2/1.3, WSSE and digest authentication for Open Network Video Interface
User/Host
Up to 32 users

3 user levels: administrator, operator, and user
ClientiVMS-4200,Hik-Connect,Hik-Central
Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Web Browser
Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+,

Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+

Image Parameters SwitchYes
Day/Night SwitchDay,Night,Auto,Schedule
Wide Dynamic Range (WDR)120 dB
SNR≥ 52 dB
Image EnhancementBLC,HLC,3D DNR
Privacy Mask8 programmable polygon privacy masks

Interface
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Reset KeyYes
Built-in Speaker1 built-in speaker,Max. power consumption: 2 W, max. sound pressure level: 10 cm: 110 dB.
AudioBuilt-in Microphone: Arrayed dual-microphone

Event
Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Smart Event
Face detection
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,audible warning,strobe light flashing

Deep Learning Function
Perimeter Protection
Line crossing, intrusion

Support alarm triggering by specified target types (human and vehicle)

General
Power
12 VDC ± 25%, 1.25 A, max. 15 W,Ø5.5 mm coaxial power plug,reverse polarity protection,

PoE: IEEE 802.3at, Class 4, max. 18 W
MaterialMetal
DimensionØ127.3 mm × 96.3 mm (Ø5″ × 3.8″)
Package Dimension150 mm × 150 mm × 141 mm (5.9″ × 5.5″ × 5.5″)
WeightApprox. 590 g (1.1 lb.)
With Package WeightApprox. 820 g (1.7 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionHeartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
Flashing Light
SRB models: Red and Blue Light

Other models: White Light

Approval
EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,

RCM: AS/NZS CISPR 32: 2015,

IC: ICES-003: Issue 7,

KC: KN32: 2015, KN35: 2015
Safety
CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017,

LOA: IEC/EN 60950-1
Environment
CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006
ProtectionIP67: IEC 60529-2013

Additional information

Models	DS-2CD2383G2-LI2U/SL(2.8mm), DS-2CD2383G2-LI2U/SL(4mm), DS-2CD2383G2-LI2U/SRB(2.8mm), DS-2CD2383G2-LI2U/SRB(4mm)
Color	White, black
