Hikvision DS-2CD26126G3-IZS2UY/S(L)(RB) 12MP Network Camera

Hikvision DS-2CD26126G3-IZS2UY/S(L)(RB) 12MP Network Camera
Hikvision DS-2CD26126G3-IZS2UY/S(L)(RB) 12MP Network Camera - Image 2
Hikvision DS-2CD26126G3-IZS2UY/S(L)(RB) 12MP Network Camera - Image 3
Hikvision DS-2CD26126G3-IZS2UY/S(L)(RB) 12MP Network Camera - Image 4

Price range: $549.00 through $569.00

SKU: N/A Category: Tags: , , , ,
📱 Contact via WhatsApp
Hikvision

Description

  • UHD: Ultra High Definition delivers lifelike immersion
  • Motorized varifocal lens for easy installation and monitoring
  • Active strobe light and audio alarm (/SL: white light, /SRB: red & blue light)
  • Excellent low-light performance via Powered by DarkFighter
  • Person and vehicle classification based on deep learning
  • Crystal-clear audio with Built-in Arrayed Dual-Mic, and Smart PA Speaker
  • Clear imaging against strong back light due to 130 dB true WDR technology
  • Water and dust resistant (IP67) and vandal resistant (IK10)
  • Anti-corrosion design, providing reliability and longevity compared to standard (NEMA 4X)
  • Tamper-free & eco-friendly packaging

Available models:

DS-2CD26126G3-IZS2UY/SL(2.8-12mm)eFO-STD
DS-2CD26126G3-IZS2UY/SRB(2.8-12)eFO-STD
DS-2CD26126G3-IZS2UY/SL(2812)eFOSTDBLACK
DS-2CD26126G3-IZS2UY/SRB(2812)eFOSTDBLK
  • Camera
  • Image Sensor1/1.8″ Progressive Scan CMOS
  • Max. Resolution4608 × 2592
  • Min. IlluminationColor: 0.0008 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
  • Shutter Time1 s to 1/100,000 s
  • Day & NightIR cut filter
  • Angle AdjustmentPan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
  • Lens
  • Lens TypeVarifocal lens, motorized lens, 2.8 to 12 mm
  • Focal Length & FOVhorizontal FOV 102° to 44°, vertical FOV 54° to 25°, diagonal FOV 123° to 51°
  • Lens MountIntegrated
  • Iris TypeFixed
  • ApertureMax. F1.2
  • Depth of Field1 m to ∞
  • DORI
  • DORI

    Wide: D: 66.6 m, O: 26.4 m, R: 13.3 m, I: 6.7 m

    Tele: D: 79.2 m, O: 31.4 m, R: 15.8 m, I: 7.9 m

  • Illuminator
  • Supplement Light TypeIR
  • Supplement Light RangeUp to 60 m
  • Smart Supplement LightYes
  • IR Wavelength850 nm
  • Video
  • Main Stream

    50Hz：

    20fps(4608 × 2592)

    25fps(3840 × 2160, 2688 × 1520, 1920 × 1080, 1280 × 720)

    60Hz：

    20fps(4608 × 2592)

    30fps(3840 × 2160, 2688 × 1520, 1920 × 1080, 1280 × 720)

  • Sub-Stream

    50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

    60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

  • Third Stream

    50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

    60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

    *Third stream is supported under certain settings.

  • Video Compression

    Main stream: H.265/H.264/H.264+/H.265+,

    Sub-stream: H.265/H.264/MJPEG,

    Third stream: H.265/H.264,

    *Third stream is supported under certain settings.

  • Video Bit Rate32 Kbps to 24 Mbps
  • H.264 TypeBaseline Profile,Main Profile,High Profile
  • H.265 TypeMain Profile
  • Bit Rate ControlCBR,VBR
  • Scalable Video Coding (SVC)H.264 and H.265 encoding
  • Region of Interest (ROI)1 fixed region for main stream
  • Audio
  • Audio Type-2U: Mono sound
  • Audio Compression-2U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio Bit Rate-2U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)
  • Audio Sampling Rate-2U: 8 kHz/16 kHz/32 kHz/48 kHz
  • Environment Noise Filtering-2U: Yes
  • Network
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
  • Simultaneous Live ViewUp to 6 channels
  • APIONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
  • User/Host

    Up to 32 users

    3 user levels: administrator, operator, and user

  • SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
  • Network StorageNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
  • ClientiVMS-4200,Hik-Connect,Hik-Central
  • Web Browser

    Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+,

    Local service: Chrome 80+, Firefox 80+, Edge 89+

  • Image
  • Image Parameters SwitchYes
  • Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
  • Day/Night SwitchDay,Night,Auto,Schedule
  • Image EnhancementBLC,HLC,3D DNR,Distortion Correction,Defog
  • SNR≥ 52 dB
  • Wide Dynamic Range (WDR)130 dB
  • Image StabilizationEIS
  • Privacy Mask4 programmable polygon privacy masks
  • Interface
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
  • Built-in SpeakerMax. power consumption: 2 W, max. sound pressure level: 10 cm: 120 dB.
  • Audio

    Built-in Microphone: Arrayed dual-microphone

    1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,

    1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

  • Alarm1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
  • Reset KeyYes
  • Event
  • Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
  • Smart EventScene change detection
  • LinkageUpload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email
  • Deep Learning Function
  • Face CaptureYes
  • Perimeter Protection

    Line crossing, intrusion, region entrance, region exiting

    Support alarm triggering by specified target types (human and vehicle)

  • General
  • Power

    12 VDC ± 25%, 1.3 A, max. 15.5 W,reverse polarity protection,

    PoE: IEEE 802.3at, Class 4, max. 18 W,2-core terminal block

  • MaterialFront cover: Metal, body: Metal, bracket: Metal
  • DimensionØ140 mm × 333.8 mm (Ø5.51″ × 13.14″)
  • Package Dimension386 mm × 190 mm × 180 mm (15.2″ × 7.5″ × 7.1″)
  • Approx. 1555 g (3.4 lb.)
  • With Package WeightApprox. 2366 g (5.2 lb.)
  • Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • General FunctionHeartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
  • Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • Flashing Light

    /SRB model: Red and Blue Light

    /SL model: White Light

  • Approval
  • EMCCE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
  • Safety

    CB: IEC 62368-1: 2014+A11,

    CE-LVD: EN 62368-1: 2014/A11: 2017

  • Environment

    CE-RoHS: 2011/65/EU,

    WEEE: 2012/19/EU,

    Reach: Regulation (EC) No 1907/2006

  • ProtectionIP67: IEC 60529-2013,IK10: IEC 62262:2002
  • Anti-Corrosion ProtectionNEMA 4X (NEMA 250-2018)

Additional information

models

DS-2CD26126G3-IZS2UY/SL, DS-2CD26126G3-IZS2UY/SRB
color

white, black

Brand

Hikvision
