Name: Hikvision DS-2CD2H86G2H-IZSY NEW 8MP Powered by Darkfighter Motorized Varifocal Turret Network AI Camera
SKU: 39238
Availability: InStock

Hikvision DS-2CD2H86G2H-IZSY NEW 8MP Powered by Darkfighter Motorized Varifocal Turret Network AI Camera - 2cd2h86g2h, camera, DS-2CD2H86G2H-IZSY, DS-2CD2H86G2H-IZSY AI CAMERA, DS-2CD2H86G2H-IZSY CAMERA, fps, Hikvision DS-2CD2H86G2H-IZSY AI CAMERA, Hikvision DS-2CD2H86G2H-IZSY CAMERA, izsy, stream

Price range: $999.00 through $1,099.00

Models

color

Clear

SKU: N/A Category: Secuity Camera Tags: 2cd2h86g2h, camera, DS-2CD2H86G2H-IZSY, DS-2CD2H86G2H-IZSY AI CAMERA, DS-2CD2H86G2H-IZSY CAMERA, fps, Hikvision DS-2CD2H86G2H-IZSY AI CAMERA, Hikvision DS-2CD2H86G2H-IZSY CAMERA, izsy, stream

📱 Contact via WhatsApp

Hikvision

Description

Motorized varifocal lens for easy installation and monitoring
Innovative socket design, highly waterproof and user-friendly
Focus on person and vehicle classification based on deep learning
Anti-corrosion design for stable protection (NEMA 4X)
Water and dust resistant (IP67) and vandal resistant (IK10)
Clear imaging against strong back light due to 120 dB WDR technology
Efficient H.265+ compression technology

Available models:

DS-2CD2H86G2H-IZSY(2.8-12mm)eFO-STDBLACK

DS-2CD2H86G2H-IZSY(2.8-12mm)(eF)

Camera
Image Sensor1/1.8″ Progressive Scan CMOS
Max. Resolution3840 × 2160
Min. IlluminationColor: 0.0008 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
Shutter Time1/3 s to 1/100,000 s
Day & NightIR cut filter
Angle AdjustmentPan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°

Lens
Lens TypeVarifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV2.8 to 12 mm, horizontal FOV 112.3° to 41.2°, vertical FOV 58.1° to 23.1°, diagonal FOV 137.4° to 47.3°
Lens MountIntegrated
ApertureMax. F1.2
Depth of Field1 m to ∞

DORI
DORI
Wide: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m

Tele: D: 220.0 m, O: 87.3 m, R: 44.0 m, I: 22.0 m

Illuminator
Supplement Light TypeIR
Supplement Light RangeUp to 40 m
Smart Supplement LightYes
IR Wavelength850 nm

Video
Main Stream
50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

60 Hz: 24 fps(3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

*Third stream is supported under certain settings.
Video Compression
Main stream: H.265/H.264/H.264+/H.265+,,

Sub-stream: H.265/H.264/MJPEG,,

Third stream: H.265/H.264,,

*Third stream is supported under certain settings.
Video Bit Rate32 Kbps to 16 Mbps
H.264 TypeBaseline Profile,Main Profile,High Profile
H.265 TypeMain Profile
Bit Rate ControlCBR,VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)1 fixed region for main stream and sub-stream

Audio
Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
Environment Noise FilteringYes

Network
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
Simultaneous Live ViewUp to 6 channels
APIONVIF (Profile S, Profile T, Profile G),ISAPI,SDK,ISUP
User/Host
Up to 32 users

3 user levels: administrator, operator, and user
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
Network StorageNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
ClientiVMS-4200,Hik-Connect,Hik-Central
Web Browser
Plug-in required live view: IE 10, IE 11,

Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,

Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Image Parameters SwitchYes
Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Day/Night SwitchDay,Night,Auto,Schedule
Wide Dynamic Range (WDR)120 dB
SNR≥ 52 dB
Image EnhancementBLC,HLC,3D DNR
Privacy Mask4 programmable polygon privacy masks

Interface
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Audio
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,

1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarm1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
Reset KeyYes

Event
Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),exception
Smart EventScene change detection
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture

Deep Learning Function
Perimeter Protection
Line crossing, intrusion, region entrance, region exiting

Support alarm triggering by specified target types (human and vehicle)
Face CaptureYes

General
Power
12 VDC ± 25%, 0.9 A, max. 10.8 W,2-core terminal block,reverse polarity protection,

PoE: IEEE 802.3af, Class 3, max. 12.95 W
MaterialBase: Metal, cover: Metal
DimensionØ143.5 mm × 142.7 mm (Ø5.7″ × 5.6″)
Package Dimension170 mm × 170 mm × 225 mm (6.7″ × 6.7″ × 8.9″)
WeightApprox. 1230 g (2.7 lb.)
With Package WeightApprox. 1490 g (3.3 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionHeartbeat,mirror,password reset via email,pixel counter,anti-banding

Approval
EMCCE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
SafetyCB: IEC 62368-1: 2014+A11
Environment
CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006,NEMA 4X (NEMA 250-2018)
ProtectionIP67: IEC 60529-2013,IK10: IEC 62262:2002
