Hikvision DS-2CD2T83G2P-LISU/S(L)(RB) 8 MP 180° Camera

Hikvision DS-2CD2T83G2P-LISU/S(L)(RB) 8 MP 180° Camera
Hikvision DS-2CD2T83G2P-LISU/S(L)(RB) 8 MP 180° Camera - Image 2
Hikvision DS-2CD2T83G2P-LISU/S(L)(RB) 8 MP 180° Camera - Image 3
Hikvision DS-2CD2T83G2P-LISU/S(L)(RB) 8 MP 180° Camera - Image 4

Price range: $279.00 through $289.00

SKU: N/A Category: Tags: , , , ,
📱 Contact via WhatsApp
Hikvision

Description

  • 180° Field of view
  • High quality imaging with 8 MP resolution
  • Support Person and Vehicle Detection
  • Smart Hybrid Light: advanced technology with long range
  • Efficient H.265+ compression technology
  • Support on-board storage up to 512 GB (SD card slot)
  • Provide real-time security via built-in two-way audio
  • Water and dust resistant (IP67)
  • Active strobe light and audio alarm to warn intruders off

Available models:

DS-2CD2T83G2P-LISU/SL(180°)
DS-2CD2T83G2P-LISU/SRB(180°)
DS-2CD2T83G2P-LISU/SL(180°)
DS-2CD2T83G2P-LISU/SRB(180°)/O-STD/BLACK
  • Camera
  • Image Sensor1/2.4″ Progressive Scan CMOS
  • Max. Resolution4256 × 1888
  • Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON),0 Lux with light
  • Shutter Time1 s to 1/100,000 s
  • Day & NightIR cut filter
  • Angle AdjustmentPan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
  • Lens
  • Lens TypeFixed focal lens, 2 mm
  • Focal Length & FOV2 mm, horizontal FOV 180°, vertical FOV 77°
  • Iris TypeFixed
  • Lens MountM12
  • ApertureF1.6
  • DORI
  • DORI2 mm, D: 50 m, O: 20 m, R: 10 m, I: 5 m
  • Illuminator
  • Supplement Light RangeUp to 30 m
  • Smart Supplement LightYes
  • Supplement Light TypeIR,White Light
  • IR Wavelength850 nm
  • Video
  • Main Stream

    50 Hz: 20 fps (4256 × 1888, 4096 × 1860)

    60 Hz: 20 fps (4256 × 1888, 4096 × 1860)

  • Sub-Stream

    50 Hz: 20 fps (1200× 536, 960 × 432)

    60 Hz: 20 fps (1200× 536, 960 × 432)

  • H.265 TypeMain Profile
  • Video Compression

    Main stream: H.265+/H.265/H.264+/H.264,

    Sub-stream: H.265/H.264/MJPEG

  • Video Bit Rate32 Kbps to 16 Mbps
  • H.264 TypeBaseline Profile,Main Profile,High Profile
  • Bit Rate ControlCBR,VBR
  • Region of Interest (ROI)1 fixed region for main stream
  • Scalable Video Coding (SVC)H.264 and H.265 encoding
  • Audio
  • Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate8 kHz/16 kHz
  • Audio TypeMono sound
  • Environment Noise FilteringYes
  • Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
  • Network
  • Web Browser

    Plug-in required live view: IE 11,

    Local service: Chrome 80+, Firefox 80+, Edge 89+

  • ClientiVMS-4200,Hik-Connect
  • SecurityPassword protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
  • Simultaneous Live ViewUp to 6 channels
  • APIONVIF (Profile S, Profile T, Profile G),ISAPI,SDK
  • ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv4, IPv6, UDP, QoS, FTP, SMTP, HTTPS, DDNS
  • User/Host

    Up to 32 users

    3 user levels: administrator, operator, and user

  • Image
  • Day/Night SwitchDay,Night,Auto,Schedule
  • Image EnhancementBLC,HLC,3D DNR
  • Wide Dynamic Range (WDR)120 dB
  • SNR≥ 52 dB
  • Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
  • Privacy Mask4 programmable polygon privacy masks
  • Interface
  • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
  • Built-in MicrophoneYes,1 built-in microphone
  • Built-in SpeakerYes, 1 built-in speaker,Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB.
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Audio

    1 input (line in), max. input amplitude: 3.3 Vpp, input impedance:4.7 KΩ, interface type: non-equilibrium

    1 output (line out), max.output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

  • Alarm1 input, 1 output (max. 12 VDC, 30 mA)
  • Reset KeyYes
  • Event
  • Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
  • Smart EventLine crossing detection, intrusion detection(support alarm triggering by specified target types (human and vehicle))
  • LinkageUpload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning, strobe light flashing
  • General
  • Power

    12 VDC ± 25%, 0.83 A, max. 10 W,Ø5.5 mm coaxial power plug,reverse polarity protection,

    PoE: IEEE 802.3af, Class 3, max. 11.5 W

  • MaterialFront cover: Metal , body: Metal, bracket: Metal
  • Dimension103.6 mm × 76 mm × 241.9 mm (4.1″ × 3.0″ × 9.52″)
  • Package Dimension260 mm × 140 mm × 115 mm (10.2″ × 5.5″ × 4.5″)
  • With Package WeightApprox. 1260 g (2.8 lb.)
  • Approx. 940 g (2.1 lb.)
  • Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • LanguageEnglish, Turkish, Polish, Romanian, Czech, Slovak, Traditional Chinese, Thai, Vietnamese, Croatian, Slovenian, Serbian, Ukrainian
  • General FunctionHeartbeat,anti-banding,password protection,password reset via email
  • Flashing Light

    /SRB model: Red and Blue Light

    /SL model: White Light

  • Approval
  • ProtectionIP67: IEC 60529-2013
  • EMCCE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
  • Safety

    CB: IEC 62368-1: 2014+A11,

    CE-LVD: EN 62368-1: 2014/A11: 2017

  • Environment

    CE-RoHS: 2011/65/EU,

    WEEE: 2012/19/EU,

    Reach: Regulation (EC) No 1907/2006

Additional information

models

DS-2CD2T83G2P-LISU/SL, DS-2CD2T83G2P-LISU/SRB
color

white, black

Brand

Hikvision
