Hikvision DS-2CV2141G2-IDW 4 MP Outdoor Network Camera

Hikvision DS-2CV2141G2-IDW 4 MP Outdoor Network Camera

$159.00

SKU: N/A Category: Tag:
📱 Contact via WhatsApp
Hikvision

Description

  • High quality imaging with 4 MP resolution
  • Realizing Wi-Fi connection and easy installation
  • Provides real-time security via built-in two-way audio
  • Efficient H.265 compression technology
  • EXIR 2.0, advanced infrared technology with long IR distance
  • Water and dust resistant (IP66)
  • Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
  • (W) version models support mobile monitoring via Hik-Connect
  • Camera
  • Image Sensor1/2.9″ Progressive Scan CMOS
  • Max. Resolution2560 × 1440
  • Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
  • Shutter Time1/3 s to 1/100,000 s
  • Day & NightIR cut filter
  • Angle Adjustmentunsupported
  • Lens
  • Lens TypeFixed focal lens, 2.8 and 4 mm optional
  • Focal Length & FOV

    2.8 mm,horizontal FOV 91°, vertical FOV 49°, diagonal FOV 108°

    4 mm, horizontal FOV 74°, vertical FOV 40°, diagonal FOV 87°

  • ApertureF1.6
  • Iris TypeFixed
  • Lens MountM12
  • Depth of Field

    2.8 mm: 1.5 m to ∞

    4 mm: 2 m to ∞

  • DORI
  • DORI

    2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m

    4 mm, D: 78 m, O: 31 m, R: 15 m, I: 7 m

  • Illuminator
  • Supplement Light TypeIR
  • Supplement Light RangeUp to 30 m
  • Smart Supplement LightYes
  • IR Wavelength850 nm
  • Video
  • Main Stream

    50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720)

    60 Hz: 20 fps (2560 × 1440), 30 fps (1920 × 1080, 1280 × 720)

  • Sub-Stream

    50 Hz: 25 fps (1280 × 720, 768 × 432, 512 × 288)

    60 Hz: 30 fps (1280 × 720, 768 × 432, 512 × 288)

  • Video Compression

    Main stream: H.265/H.264

    Sub-stream: H.265/H.264

  • Video Bit Rateup to 2 Mbps
  • H.264 TypeBaseline Profile,Main Profile,High Profile
  • H.265 TypeMain Profile
  • Bit Rate ControlCBR,VBR
  • Audio
  • Audio CompressionG.711ulaw/G.711alaw/AAC-LC
  • Audio Bit Rate64 Kbps (G.711)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate8 kHz/16 kHz
  • Environment Noise FilteringYes
  • Network
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv4, UDP, Bonjour, SSL/TLS
  • Simultaneous Live ViewUp to 4 channels
  • APIONVIF, SDK
  • SecurityPassword protection, HTTPS encryption, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE for Open Network Video Interface
  • User/Hostadministrator
  • Network Storageunsupported
  • ClientiVMS-4200, Hik-Connect, Hik-Partner-Pro
  • Web Browserunsupported
  • Wi-Fi
  • Wi-Fi ProtocolIEEE802.11b, 802.11g, 802.11n
  • Frequency Range2.412 GHz to 2.472 GHz
  • Channel Bandwidth20 MHz
  • Modulation

    802.11b: CCK, QPSK, BPSK

    802.11g: OFDM

    802.11n: OFDM

  • Transfer Rate

    11b: up to 54 Mbps,

    11g: up to 54 Mbps,

    11n: up to 150 Mbps

  • Wireless Range

    Up to 120 m

    (The performance varies based on actual environment)

  • Antenna2 Antennas
  • Image
  • Image Settingssaturation, brightness, contrast, sharpness, adjustable by client software
  • Day/Night SwitchAuto, Schedule, Day, Night
  • Wide Dynamic Range (WDR)Digital WDR
  • SNR≥ 52 dB
  • Image Enhancementunsupported
  • Privacy Mask4 programmable polygon privacy masks
  • Interface
  • Built-in MicrophoneYes, 1 built-in microphone
  • Built-in SpeakerYes, 1 built-in speaker
  • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
  • Reset KeyYes
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Event
  • Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),exception
  • Linkage

    Upload to memory card, notify surveillance center, trigger capture, audible warning, auto-tracking lite

  • General
  • Power12 VDC ± 10%, 1A, max. 10 W, Φ2 mm coaxial power plug, reverse polarity protection
  • Languageunsupported
  • Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • General FunctionHeartbeat, mirror
  • Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • MaterialBase: metal, front cover: polycarbonate, back cover: polycarbonate
  • Dimension120 mm × 120 mm × 95 mm (4.7″ × 4.7″ × 3.7″)
  • Package Dimension170 mm × 170 mm × 150 mm (6.7″ × 6.7″ × 5.9″)
  • WeightApprox. 593 g (1.3 lb.)
  • With Package WeightApprox. 886 g (1.95 lb.)
  • Approval
  • EMCCE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014
  • RFCE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G));
  • Safety

    CB: IEC 62368-1: 2014+A11,

    CE-LVD: EN 62368-1: 2014/A11: 2017

  • Environment

    CE-RoHS: 2011/65/EU,

    WEEE: 2012/19/EU

  • ProtectionIP66: IEC 60529-2013
