Name: Hikvision iDS-2CD5A46G2/V-XZ(H)S(Y) NEW 4MP DeepinViewX Moto Varifocal Bullet Camera
SKU: 38872
Availability: InStock

Hikvision iDS-2CD5A46G2/V-XZ(H)S(Y) NEW 4MP DeepinViewX Moto Varifocal Bullet Camera for Perimeter Protection - 2cd5a46g2, detection, Hikvision iDS-2CD5A46G2/V-XZ(H)S(Y), Hikvision iDS-2CD5A46G2/V-XZ(H)S(Y) camera, ids, iDS-2CD5A46G2/V-XZ(H)S(Y), iDS-2CD5A46G2/V-XZ(H)S(Y) camera, protection, stream

Price range: $599.00 through $649.00

Models

Clear

SKU: N/A Category: Secuity Camera Tags: 2cd5a46g2, detection, Hikvision iDS-2CD5A46G2/V-XZ(H)S(Y), Hikvision iDS-2CD5A46G2/V-XZ(H)S(Y) camera, ids, iDS-2CD5A46G2/V-XZ(H)S(Y), iDS-2CD5A46G2/V-XZ(H)S(Y) camera, protection, stream

📱 Contact via WhatsApp

Hikvision

Description

High quality imaging with 4 MP resolution
Excellent low-light performance via DarkFighter2.0 technology
Efficient H.265+ compression technology to save bandwidth and storage
Water and dust resistant (IP67), vandal proof (IK10) and corrosion resistant (NEMA 4X, optional)
Built-in front window heater to ensure clear image under rainy or snowy weather
Dedicated large scale AI model for perimeter protection, reduce false alarms by 90% compared to conventional AI cameras

Available models:

iDS-2CD5A46G2/V-XZHSY(2.8-12mm)

iDS-2CD5A46G2/V-XZS(2.8-12mm)

Camera
Image Sensor1/1.8″ Progressive Scan CMOS
Max. Resolution2688 × 1520
Min. IlluminationColor: 0.0014 Lux @ (F1.0, AGC ON),B/W: 0.0005 Lux @ (F1.0, AGC ON),B/W: 0 Lux with IR
Shutter Time1 s to 1/100,000 s
Day & Night
IR cut filter,

Blue glass module (less ghost phenomenon)

Lens
Focal Length & FOV2.8 to 12 mm, horizontal FOV 114.3° to 48.2°, vertical FOV 59.3° to 27.2°, diagonal FOV 141.6° to 55.5°
Iris TypeDC iris
ApertureF1.47 to F2.53

DORI
DORI
Wide: D (Detect) : 60.7 m, O (Observe) : 24.1 m, R (Recognize) : 12.1 m, I (Identify) : 6.1 m

Tele: D (Detect) : 128.3 m, O (Observe) : 50.9 m, R (Recognize) : 25.7 m, I (Identify) : 12.8 m

The DORI values are calculated using pixel densities for different use cases as recommended by the EN 62676-4 standard.

Illuminator
Supplement Light TypeIR,White Light
Supplement Light Range
IR: up to 80 m

White Light: up to 60 m
Smart Supplement LightYes
IR Wavelength850 nm

Video
Main Stream
50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)

60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480)

60 Hz: 30 fps (704 × 480, 640 × 480)
Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream
50 Hz: 25fps (704 × 576, 640 × 480)

60 Hz: 30fps (704 × 480, 640 × 480)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG,

Third stream: H.265/H.264,

Fourth stream: H.265/H.264/MJPEG
Video Bit Rate32 Kbps to 8 Mbps
H.264 TypeBaseline Profile,Main Profile,High Profile
H.265 TypeMain Profile
Bit Rate ControlCBR,VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)8 fixed regions for each stream

Audio
Audio TypeMono sound
Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
Environment Noise FilteringYes

Network
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets
Simultaneous Live ViewUp to 20 channels
APIISAPI,SDK,ISUP,OTAP,ONVIF (Profile S, Profile G, Profile T, Profile M)
User/Host
Up to 32 users

3 user levels: administrator, operator, and user
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, AES128/256
Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200,Hik-Connect,Hik-Central
Web Browser
Plug-in required live view: IE 10, IE 11,

Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,

Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Image Parameters SwitchYes
Image SettingsRotate mode,saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
Day/Night SwitchDay,Night,Auto,Schedule,Alarm Trigger
Wide Dynamic Range (WDR)120 dB
Image EnhancementBLC,HLC,3D DNR,Distortion Correction,Defog
Privacy Mask8 programmable polygon privacy masks
SNR≥ 52 dB
Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
Image StabilizationEIS

Interface
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB
Alarm1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
Built-in Microphone2 built-in microphones
Audio
1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,

1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
Built-in Speaker1 built-in speaker,Max. power consumption: 1.5 W
RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset KeyYes
Power Output
12 VDC, max. 100 mA

External extension cord less than 10 meters.

Event
Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,video quality diagnosis,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error)
Smart EventScene change detection,audio exception detection,defocus detection, unattended baggage detection, object removal detection, loitering detection, people gathering detection, fast moving detection, parking detection
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning

Deep Learning Function
Perimeter Protection
Line crossing, intrusion, region entrance, region exiting

Support alarm triggering by specified target types (human and vehicle)

Support combined event alarm triggering

Dedicated large scale AI model for perimeter protection, reduce false alarms by 90% compared to conventional AI cameras

VCA range: up to 80m(nighttime)/100m(daytime)

*Result based on standard setup and test environment
MetadataIntrusion detection,line crossing detection,region entrance detection,region exiting detection
AcuSeekSupport search for humans, vehicles, This function requires use with AcuSeek NVR/Servers.

General
Power
two-core terminal block,

12 VDC ± 20%, 1.6 A, max. 19.2 W,

PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.54 A to 0.4 A, max. 22.8 W
MaterialAluminum alloy body
Dimension323.4 mm × 114.5 mm × 114.5 mm (12.73″ × 4.51″ × 4.51″)
Package Dimension386 mm × 156 mm × 155 mm (15.3″ × 6.2″ × 6.2″)
WeightApprox. 1450 g (3.2 lb.)
With Package WeightApprox. 2169 g (4.78 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions
With -H: -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing),

Without -H: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionHeartbeat,anti-banding,one-key reset,mirror,password protection,flash log
HeaterYes
DemistYes
Integrated Connector PanelNo

Approval
EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,

RCM: AS/NZS CISPR 32: 2015
SafetyCB: IEC 62368-1: 2014+A11
Environment
CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006
ProtectionIP67: IEC 60529-2013,IK10: IEC 62262:2002
Anti-Corrosion Protection-Y: NEMA 4X (NEMA 250-2018)
