Hikvision iDS-2CD7186G2/LM-IZ(H)S(Y) NEW 8MP DeepinViewX Moto Varifocal Dome Camera

IR cut filter,

Blue glass module (less ghost phenomenon)

2.8 to 12 mm, horizontal FOV 112.0° to 47.5°, vertical FOV 58.0° to 26.6°, diagonal FOV 137.5° to 54.6°

8 to 32 mm, horizontal FOV 41.8° to 15.0°, vertical FOV 22.9° to 8.5°, diagonal FOV 48.7° to 17.1°

2.8 to 12 mm: F1.4 to F2.1

8 to 32 mm: F1.7 to F1.7

Wide:

2.8mm to 12mm: D (Detect) : 88 m, O (Observe) : 34.9 m, R (Recognize) : 17.6 m, I (Identify) : 8.8 m

8mm to 32mm: Wide: D (Detect) : 218 m, O (Observe) : 86.5 m, R (Recognize) : 43.6 m, I (Identify) : 21.8 m

Tele:

2.8mm to 12mm: D (Detect) : 186 m, O (Observe) : 73.8 m, R (Recognize) : 37.2 m, I (Identify) : 18.6 m

8mm to 32mm: D (Detect) : 580 m, O (Observe) : 230.2 m, R (Recognize) : 116 m, I (Identify) : 58 m

The DORI values are calculated using pixel densities for different use cases as recommended by the EN 62676-4 standard.

1. Up to 3 models. Model type: detection model, classification model, mixed model (detection model and classification model).

2. Supports video analysis (detection, classification, mixed, OCR, segmentation, comparison) and scheduled capture analysis (classification).

(1) Detection: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection.

(2) Classification: Region exception status detection, full analysis rule.

(3) Mixed: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule; area overlap ratio counting, area overlap ratio exception detection.

(4) Picture Comparison: Area status change detection.

(5) OCR: OCR-triggered capture.

(6) OVD: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection.

3. Supports 4 model packages, each capable of detecting 16 target types and classifying 4 targets. The targets can be classified as 64 types. The device runs only 1 model at the same time.

4. Built-in models for PPE detection (hard hat and reflective clothing).

50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)

60 Hz: 30 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)

50 Hz: 25 fps (704 × 576, 640 × 480)

60 Hz: 30 fps (704 × 480, 640 × 480)

50 Hz:25 fps(1920 × 1080,1280 × 720,704 × 576,640 × 480)

60 Hz:30 fps(1920 × 1080,1280 × 720,704 × 480,640 × 480)

Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG,

Third stream: H.265/H.264

Up to 32 users

3 user levels: administrator, operator, and user

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

Plug-in required live view: IE 10, IE 11,

Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,

Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,

1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
