Hikvision iDS-2CD7A46G2/LM-IZHS(Y) NEW 4MP DeepinViewX Moto Varifocal Bullet Camera

Hikvision iDS-2CD7A46G2/LM-IZHS(Y) NEW 4MP DeepinViewX Moto Varifocal Bullet Camera - detection, Hikvision iDS-2CD7A46G2/LM-IZHS(Y), Hikvision iDS-2CD7A46G2/LM-IZHS(Y) camera, iDS-2CD7A46G2/LM-IZHS(Y), iDS-2CD7A46G2/LM-IZHS(Y) camera, max, model, region, target

Price range: $549.00 through $649.00

SKU: N/A Category: Tags: , , , , , , , ,
📱 Contact via WhatsApp
Hikvision

Description

  • High quality imaging with 4 MP resolution
  • Excellent low-light performance via DarkFighter2.0 technology
  • Clear imaging against strong back light due to 150 dB WDR technology
  • Efficient H.265+ compression technology to save bandwidth and storage
  • 5 streams to meet a wide variety of applications
  • Water and dust resistant (IP67), vandal proof (IK10) and corrosion resistant (NEMA 4X, optional)
  • Built-in heater to ensure clear image under rainy or snowy weather
  • Supports Guanlan large model algorithms, license plate recognition, vehicle attribute analysis, perimeter protection, AIOP with built-in PPE detection model
  • Capable of loading trained large model algorithm packages from the AI training platform

Available models:

iDS-2CD7A46G2/LM-IZHS(2.8-12mm)
iDS-2CD7A46G2/LM-IZHS(8-32mm)
iDS-2CD7A46G2/LM-IZHSY(2.8-12mm)
iDS-2CD7A46G2/LM-IZHSY(8-32mm)
  • Camera
  • Image Sensor1/1.8″ Progressive Scan CMOS
  • Max. Resolution2688 × 1520
  • Min. IlluminationColor: 0.0005 Lux @ (F1.2, AGC ON),B/W: 0.0001 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR,0 Lux with light
  • Shutter Time1 s to 1/100,000 s
  • Day & Night

    IR cut filter,

    Blue glass module (less ghost phenomenon)

  • Lens
  • Focal Length & FOV

    2.8 to 12 mm, horizontal FOV 112.5° to 47.7°, vertical FOV 58.2° to 26.7°, diagonal FOV 138.2° to 54.8°

    8 to 32 mm, horizontal FOV 42.5° to 15.2°, vertical FOV 23.4° to 8.7°, diagonal FOV 49.7° to 17.3°

  • FocusAuto,Semi-auto,Manual
  • Iris TypeP-iris
  • Aperture

    2.8 to 12 mm: F1.4 to F2.1

    8 to 32 mm: F1.7 to F1.7

  • DORI
  • DORI

    Wide:

    2.8mm to 12mm: D (Detect) : 60.7 m, O (Observe) : 24.1 m, R (Recognize) : 12.1 m, I (Identify) : 6.1 m

    8mm to 32mm: D (Detect) : 150.3 m, O (Observe) : 59.7 m, R (Recognize) : 30.1 m, I (Identify) : 15 m

    Tele:

    2.8mm to 12mm: D (Detect) : 128.3 m, O (Observe) : 50.9 m, R (Recognize) : 25.7 m, I (Identify) : 12.8 m

    8mm to 32mm: D (Detect) : 400 m, O (Observe) : 158.7 m, R (Recognize) : 80 m, I (Identify) : 40 m

    The DORI values are calculated using pixel densities for different use cases as recommended by the EN 62676-4 standard.

  • Illuminator
  • Supplement Light TypeIR
  • Supplement Light Range2.8 to 12 mm: Monitoring: 60 m; 8 to 32 mm: Monitoring: 100 m
  • Smart Supplement LightYes
  • IR Wavelength850 nm
  • AI Open Platform
  • Model Specification

    1. Up to 3 models. Model type: detection model, classification model, mixed model (detection model and classification model).

    2. Supports video analysis (detection, classification, mixed, OCR, segmentation, comparison) and scheduled capture analysis (classification).

    (1) Detection: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection.

    (2) Classification: Region exception status detection, full analysis rule.

    (3) Mixed: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule; area overlap ratio counting, area overlap ratio exception detection.

    (4) Picture Comparison: Area status change detection.

    (5) OCR: OCR-triggered capture.

    (6) OVD: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection.

    3. Supports 4 model packages, each capable of detecting 16 target types and classifying 4 targets. The targets can be classified as 64 types. The device runs only 1 model at the same time.

    4. Built-in models for PPE detection (hard hat and reflective clothing).

  • Video
  • Main Stream

    50 Hz:25 fps(2688 × 1520,2560 × 1440,1920 × 1080,1280 × 720)

    60 Hz:30 fps(2688 × 1520,2560 × 1440,1920 × 1080,1280 × 720)

  • Sub-Stream

    50 Hz: 25 fps (704 × 576, 640 × 480)

    60 Hz: 30 fps (704 × 480, 640 × 480)

  • Third Stream

    50 Hz:25 fps(1920 × 1080,1280 × 720,704 × 576,640 × 480)

    60 Hz:30 fps(1920 × 1080,1280 × 720,704 × 480,640 × 480)

  • Video Compression

    Main stream: H.265+/H.265/H.264+/H.264,

    Sub-stream: H.265/H.264/MJPEG,

    Third stream: H.265/H.264

  • Video Bit Rate32 Kbps to 8 Mbps
  • H.264 TypeBaseline Profile,Main Profile,High Profile
  • H.265 TypeMain Profile
  • Bit Rate ControlCBR,VBR
  • Scalable Video Coding (SVC)H.264 and H.265 encoding
  • Region of Interest (ROI)4 fixed regions for each stream
  • Target CroppingNo
  • e-PTZSupport Patrol and Auto Tracking settings
  • Audio
  • Audio TypeMono sound
  • Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
  • Environment Noise FilteringYes
  • Network
  • ProtocolsIPv6,RTP,ICMP,PPPoE,DNS,WebSocket,TCP/IP,SSL/TLS,HTTPS,RTSP,IGMP,SNMP,NTP,SMTP,WebSockets,SFTP,UPnP,DHCP,802.1X,IPv4,FTP,UDP,QoS,RTCP,HTTP,DDNS
  • Simultaneous Live ViewUp to 20 channels
  • APIISAPI,SDK,ISUP,OTAP,ONVIF (Profile S, Profile G, Profile T, Profile M)
  • User/Host

    Up to 32 users

    3 user levels: administrator, operator, and user

  • SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2, CC EAL4+), AES128/256
  • Network Storage

    NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

    Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

  • ClientiVMS-4200,Hik-Connect,Hik-Central
  • Web Browser

    Plug-in required live view: IE 10, IE 11,

    Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,

    Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

  • Image
  • Image Parameters SwitchYes
  • Image SettingsRotate mode,saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
  • Day/Night SwitchDay,Night,Auto,Schedule,Alarm Trigger
  • Wide Dynamic Range (WDR)150 dB
  • Image EnhancementBLC,HLC,3D DNR,Distortion Correction,Defog
  • Privacy Mask8 programmable polygon privacy masks
  • SNR≥ 52 dB
  • Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
  • Image StabilizationEIS
  • Interface
  • Video Output1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
  • Ethernet Interface1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
  • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB
  • Alarm2 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A)
  • Built-in Microphone2 built-in microphones
  • Audio

    1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,

    1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound

  • Built-in Speaker1 built-in speaker,Max. power consumption: 1.5 W
  • RS-485-Y: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
  • Reset KeyYes
  • Power Output-Y: 12VDC,max.100mA,External extension cord less than 10 meters.
  • Event
  • Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,video quality diagnosis,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),vibration detection
  • Smart Eventscene change detection,audio exception detection,defocus detection, unattended baggage detection,loitering detection,object removal detection,people gathering detection,fast moving detection,parking detection
  • LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning
  • Deep Learning Function
  • Perimeter Protection

    Line crossing, intrusion, region entrance, region exiting

    Support alarm triggering by specified target types (human and vehicle)

    Support combined event alarm triggering

  • MetadataIntrusion detection,line crossing detection,region entrance detection,region exiting detection
  • Road Traffic and Vehicle Detection

    Accuracy (under recommended installation and lighting conditions)

    Capture rate > 98%

    Vehicle moving direction recognition accuracy > 96%

    Mistaken capture rate < 2% (entrance/exit), < 5% (checkpoint)

    Blocklist and allowlist: up to 10000 records

    Captures vehicle that has no license plate

    Support license plate recognition of motorcycles (only in checkpoint scenario)

    Support vehicle attribute detection, including vehicle type, color, brand, etc. (City Street mode is recommended.)

  • General
  • Power

    three-core terminal block,

    -Y：

    12 VDC ± 20%, 2.08 A, max. 24.95 W,

    24 VAC ± 20%, 1.52 A, max. 24.05 W,

    PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.58 A to 0.44 A, max. 24.95 W

    without Y：

    12 VDC ± 20%, 1,97 A, max. 23.6 W,

    24 VAC ± 20%, 1.46 A, max. 22.84 W,

    PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.55 A to 0.42 A, max. 23.6 W

  • MaterialAluminum alloy body
  • DimensionWith -Y: Ø140 mm × 377.4 mm (Ø5.5″ × 14.9″), Without -Y: Ø144.1 mm × 374.7 mm (Ø5.7″ × 14.8″)
  • Package Dimension425 mm × 190 mm × 180 mm (16.7″ × 7.5″ × 7.1″)
  • WeightApprox. 2280 g (5.03 lb.)
  • With Package WeightWithout -Y: Approx. 3364 g (7.42 lb.), -Y: Approx. 3406 g (7.5 lb.)
  • Storage Conditions-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
  • Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General FunctionHeartbeat,anti-banding,one-key reset,mirror,password protection,flash log
  • HeaterYes
  • DemistYes
  • Device ManagementSupports adding alarm box (DS-FM2466) in the LAN to expand 6 additional input and 6 output alarm interfaces
  • Integrated Connector Panel-Y: No
  • Approval
  • EMC

    CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,

    RCM: AS/NZS CISPR 32: 2015

  • Safety

    CB: IEC 62368-1: 2014+A11,

    CE-LVD: EN 62368-1: 2014/A11: 2017,

    LOA: IEC/EN 60950-1

  • Environment

    CE-RoHS: 2011/65/EU,

    WEEE: 2012/19/EU,

    Reach: Regulation (EC) No 1907/2006

  • ProtectionIP67: IEC 60529-2013,IK10: IEC 62262:2002
  • Anti-Corrosion Protection-Y: NEMA 4X (NEMA 250-2018)
  • OtherPVC FREE

Additional information

Models

iDS-2CD7A46G2/LM-IZHS(2.8-12mm), iDS-2CD7A46G2/LM-IZHS(8-32mm), iDS-2CD7A46G2/LM-IZHSY(2.8-12mm), iDS-2CD7A46G2/LM-IZHSY(8-32mm)
