Hikvision IDS-2CD7A86G2/V-XZHS(Y) NEW 8MP DeepinViewX Moto Varifocal Bullet Camera for Perimeter Protection

Hikvision IDS-2CD7A86G2/V-XZHS(Y) NEW 8MP DeepinViewX Moto Varifocal Bullet Camera for Perimeter Protection - detection, fps, Hikvision IDS-2CD7A86G2/V-XZHS(Y), Hikvision IDS-2CD7A86G2/V-XZHS(Y) camera, IDS-2CD7A86G2/V-XZHS(Y), IDS-2CD7A86G2/V-XZHS(Y) camera, max, stream, video
Hikvision IDS-2CD7A86G2/V-XZHS(Y) NEW 8MP DeepinViewX Moto Varifocal Bullet Camera for Perimeter Protection - detection, fps, Hikvision IDS-2CD7A86G2/V-XZHS(Y), Hikvision IDS-2CD7A86G2/V-XZHS(Y) camera, IDS-2CD7A86G2/V-XZHS(Y), IDS-2CD7A86G2/V-XZHS(Y) camera, max, stream, video
Hikvision IDS-2CD7A86G2/V-XZHS(Y) NEW 8MP DeepinViewX Moto Varifocal Bullet Camera for Perimeter Protection - detection, fps, Hikvision IDS-2CD7A86G2/V-XZHS(Y), Hikvision IDS-2CD7A86G2/V-XZHS(Y) camera, IDS-2CD7A86G2/V-XZHS(Y), IDS-2CD7A86G2/V-XZHS(Y) camera, max, stream, video
Hikvision IDS-2CD7A86G2/V-XZHS(Y) NEW 8MP DeepinViewX Moto Varifocal Bullet Camera for Perimeter Protection - detection, fps, Hikvision IDS-2CD7A86G2/V-XZHS(Y), Hikvision IDS-2CD7A86G2/V-XZHS(Y) camera, IDS-2CD7A86G2/V-XZHS(Y), IDS-2CD7A86G2/V-XZHS(Y) camera, max, stream, video

Price range: $749.00 through $799.00

SKU: N/A Category: Tags: , , , , , , , ,
📱 Contact via WhatsApp
Hikvision

Description

  • High quality imaging with 8 MP resolution
  • Excellent low-light performance via DarkFighter technology
  • Clear imaging against strong back light due to 120 dB WDR technology
  • Efficient H.265+ compression technology to save bandwidth and storage
  • 5 streams to meet a wide variety of applications
  • Water and dust resistant (IP67), vandal proof (IK10) and corrosion resistant (NEMA 4X, optional)
  • Built-in heater to ensure clear image under rainy or snowy weather
  • Dedicated large scale AI model for perimeter protection, reduce false alarms by 90% compared to conventional AI cameras

Available models:

iDS-2CD7A86G2/V-XZHSY(2.8-12mm)
iDS-2CD7A86G2/V-XZHSY(8-32mm)
  • Camera
  • Image Sensor1/1.8″ Progressive Scan CMOS
  • Max. Resolution3840 × 2160
  • Min. IlluminationColor: 0.0005 Lux @ (F1.2, AGC ON),B/W: 0.0001 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR,0 Lux with light
  • Shutter Time1 s to 1/100,000 s
  • Day & Night

    IR cut filter,

    Blue glass module (less ghost phenomenon)

  • Lens
  • Focal Length & FOV2.8 to 12 mm, horizontal FOV 104° to 41.2°, vertical FOV 54.2° to 23.1°, diagonal FOV 126.5° to 47.3°
  • FocusAuto,Semi-auto,Manual
  • Iris TypeP-iris
  • Aperture2.8 to 12 mm: F1.47 to F2.5
  • DORI
  • DORI

    Wide:

    2.8 to 12 mm: D (Detect): 93.8 m, O (Observe): 37.2 m, R (Recognize): 18.8 m, I (Identify): 9.4 m

    Tele:

    2.8 to 12 mm: D (Detect): 220 m, O (Observe): 87.3 m, R (Recognize): 44.0 m, I (Identify): 22.0 m

    The DORI values are calculated using pixel densities for different use cases as recommended by the EN 62676-4 standard.

  • Illuminator
  • Supplement Light TypeIR,White Light
  • Supplement Light RangeUp to 100 m
  • Smart Supplement LightYes
  • IR Wavelength850 nm
  • Video
  • Main Stream

    Monitoring mode:

    50 Hz: up to 50 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1280 × 720), up to 100 fps (1920 × 1080)

    60 Hz: up to 60 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1280 × 720), up to 120 fps (1920 × 1080)

    *High frame rate is supported under monitoring mode only.

    smart mode:

    50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)

    60 Hz: 30 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)

  • Sub-Stream

    50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)

    60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480)

  • Third Stream

    50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

    60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)

  • Fourth Stream

    50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)

    60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480)

  • Fifth Stream

    50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)

    60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480)

  • Video Compression

    Main stream: H.265+/H.265/H.264+/H.264,

    Sub-stream: H.265/H.264/MJPEG,

    Third stream: H.265/H.264,

    Fourth stream: H.265/H.264/MJPEG,

    Fifth stream: H.265/H.264/MJPEG

  • Video Bit Rate32 Kbps to 16 Mbps
  • H.264 TypeBaseline Profile,Main Profile,High Profile
  • H.265 TypeMain Profile
  • Bit Rate ControlCBR,VBR
  • Scalable Video Coding (SVC)H.264 and H.265 encoding
  • Region of Interest (ROI)4 fixed regions for each stream
  • Target CroppingYes
  • e-PTZSupport Patrol and Auto Tracking settings
  • Audio
  • Audio TypeMono sound
  • Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate8 kHz/16 kHz/32 kHz/48 kHz
  • Environment Noise FilteringYes
  • Network
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets
  • Simultaneous Live ViewUp to 20 channels
  • APIISAPI,SDK,ISUP,OTAP,ONVIF (Profile S, Profile G, Profile T, Profile M)
  • User/Host

    Up to 32 users

    3 user levels: administrator, operator, and user

  • SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256
  • Network Storage

    NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

    Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

  • ClientiVMS-4200,Hik-Connect,Hik-Central
  • Web Browser

    Plug-in required live view: IE 10, IE 11,

    Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,

    Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

  • Image
  • Image Parameters SwitchYes
  • Image SettingsRotate mode,saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
  • Day/Night SwitchDay,Night,Auto,Schedule,Alarm Trigger
  • Wide Dynamic Range (WDR)120 dB
  • Image EnhancementBLC,HLC,3D DNR,Distortion Correction,Defog
  • Privacy Mask8 programmable polygon privacy masks
  • SNR≥ 52 dB
  • Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
  • Image StabilizationEIS
  • Interface
  • Video Output1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
  • Ethernet Interface1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
  • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB
  • Alarm2 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A)
  • Built-in Microphone2 built-in microphones
  • Audio

    1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,

    1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound

  • Built-in Speaker1 built-in speaker,Max. power consumption: 1.5 W
  • RS-485-Y: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
  • Reset KeyYes
  • Power Output-Y: 12 VDC, max. 100 mA
  • Event
  • Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,video quality diagnosis,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),vibration detection
  • Smart Eventscene change detection,audio exception detection,defocus detection
  • LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning
  • Deep Learning Function
  • Perimeter Protection

    Line crossing, intrusion, region entrance, region exiting

    Support alarm triggering by specified target types (human and vehicle)

    Support combined event alarm triggering

    Dedicated large scale AI model for perimeter protection, reduce false alarms by 90% compared to conventional AI cameras

    VCA range: up to 80m(nighttime)/100m(daytime)

    *Result based on standard setup and test environment

  • MetadataIntrusion detection,line crossing detection,region entrance detection,region exiting detection
  • General
  • Power

    three-core terminal block,

    12 VDC ± 20%, 2 A, max. 24 W,

    24 VAC ± 20%, 1.6 A, max. 23.8 W,

    PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.59 A to 0.44 A, max. 24.7 W

  • MaterialAluminum alloy body
  • DimensionWith -Y: Ø140 mm × 377.4 mm (Ø5.5″ × 14.9″), Without -Y: Ø144.1 mm × 374.7 mm (Ø5.7″ × 14.8″)
  • Package Dimension425 mm × 190 mm × 180 mm (16.7″ × 7.5″ × 7.1″)
  • Approx. 2280 g (5.03 lb.)
  • With Package WeightWithout -Y: Approx. 3364 g (7.42 lb.), -Y: Approx. 3406 g (7.5 lb.)
  • Storage Conditions-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
  • Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General FunctionHeartbeat,anti-banding,one-key reset,mirror,password protection,flash log
  • HeaterYes
  • DemistYes
  • Device ManagementSupports adding alarm box (DS-FM2466) in the LAN to expand 6 additional input and 6 output alarm interfaces
  • Integrated Connector Panel-Y: No
  • Approval
  • EMC

    CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,

    RCM: AS/NZS CISPR 32: 2015,

    IC: ICES-003: Issue 7,

    KC: KN32: 2015, KN35: 2015

  • Safety

    CB: IEC 62368-1: 2014+A11,

    CE-LVD: EN 62368-1: 2014/A11: 2017,

    BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,

    LOA: IEC/EN 60950-1

  • Environment

    CE-RoHS: 2011/65/EU,

    WEEE: 2012/19/EU,

    Reach: Regulation (EC) No 1907/2006

  • ProtectionIP67: IEC 60529-2013,IK10: IEC 62262:2002
  • Anti-Corrosion Protection-Y: NEMA 4X (NEMA 250-2018)
  • Automotive and RailwayEN50121-4
  • OtherPVC FREE

Additional information

Models

iDS-2CD7A86G2/V-XZHSY(2.8-12mm), iDS-2CD7A86G2/V-XZHSY(8-32mm)
