IPC-HFW3849T1-AS-PV-PRO 8MP WizColor TiOC PRO Fixed-focal Bullet WizSense Network Camera

Sale!
IPC-HFW3849T1-AS-PV-PRO 8MP WizColor TiOC PRO Fixed-focal Bullet WizSense Network Camera
IPC-HFW3849T1-AS-PV-PRO 8MP WizColor TiOC PRO Fixed-focal Bullet WizSense Network Camera - Image 2
IPC-HFW3849T1-AS-PV-PRO 8MP WizColor TiOC PRO Fixed-focal Bullet WizSense Network Camera - Image 3

Original price was: $289.99.Current price is: $279.99.

SKU: N/A Category: Tag: Brand:
📱 Contact via WhatsApp

Description

DH-IPC-HFW3849T1-AS-PV-PRO 8MP WizColor TiOC PRO Fixed-focal Bullet WizSense Network Camera
Key Points

High-Quality Imaging with 8 MP Resolution

Exceptional Image Quality in Low-Light Environments by WizColor Technology

Red & Blue Warning Lights and Alarm Sounds for Active Deterrence

Xinghan Vision Models: Comprehensive Enhancement of Target Detection, Imaging

Enhanced Deep Learning-Based Human and Vehicle Classification

AcuPick Enables Fast and Precise Human&Vehicle Search

Built-in Dual Mic & Speaker: Secure Real-Time Talk

IP67 for Protection Against Harsh Environments

Technical Specification
Camera
Image Sensor 1/1.8″ CMOS
Max. Resolution 3840 (H) × 2160 (V)
ROM 256 MB
RAM 1 GB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.0008 [email protected] (Color, 30IRE)

0.0004 [email protected] (B/W, 30IRE)

0 lux (Illuminator on)
S/N Ratio >56 dB
Illumination Distance Up to 60 m (196.85 ft) (IR)

Up to 50 m (164.04 ft) (Warm light)
Illuminator On/Off Control Auto;Manual
Illuminator Number 4 (Multi-core (IR + warm) light)
Angle Adjustment Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Lens Mount M16
Focal Length 2.8 mm;3.6 mm
Max. Aperture F1.0
Field of View 2.8 mm: H: 109°; V: 59°; D: 131°

3.6 mm: H: 93; V: 50°; D: 111°
Iris Control Fixed
Close Focus Distance 2.8 mm: 3.2 m (10.50 ft)

3.6 mm: 4.4 m (14.44 ft)
DORI Distance Lens Detect Observe Recognize Identify
2.8 mm 82.0 m

(269.03 ft)

 32.8 m

(107.64 ft)

 16.4 m

(53.81 ft)

 8.2 m

(26.90 ft)
3.6 mm 100.0 m

(328.08 ft)

 40.2 m

(131.23 ft)

 20.0 m

(65.62 ft)

 10.0 m

(32.81 ft)
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Intelligence
IVS (Perimeter Protection) Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human), stay detection, loitering detection.
Face Detection(Full Image) Face detection; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting.
SMD SMD 4.0
Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
AcuPick Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.
AI SSA Adopt deep learning algorithms to adjust the parameters

of the image to suit the conditions.
Video
Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by sub stream)
AI Coding AI H.265; AI H.264

*Includes smart codec technology, Smart H.265+ and Smart H.264+
Video Frame Rate Main stream: 3840 × 2160@(1 fps–25/30 fps)
Sub stream: 1920 × 1080@(1 fps–25/30 fps)

Third stream: 1920 × 1080@(1 fps–25/30 fps)
*The values above are the max. frame rates of each stream; for multple streams, the values will be subjected to the total encoding capacity.
Stream Capability 3 streams
Resolution 8M (3840 × 2160); 6M (3200 × 1800); 5M (3072 × 1728); 4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control VBR; CBR; ABR
Video Bit Rate H.264: 3 kbps–16384 kbps
H.265: 3 kbps–16384 kbps
Day/Night Auto(ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
Scene Self-adaptation (SSA) Yes
White Balance Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control Auto/Manual
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Smart Illumination Yes
Smart Dual Light Yes
Defog Yes
Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror Yes
Privacy Masking 8 areas
LDC Yes
Audio
Built-in MIC Yes, built-in dual Mic
Built-in Speaker Yes, built-in speaker

Max power consumption: 2 W; max sound level at 10 cm: 110 dB

* Test results from laboratory
Audio Compression PCM; G.711a; G.711Mu; G.726; G.723
Alarm
Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; stay detection; loitering detection; face detection (full image); scene changing; audio detection; voltage detection; SMD; security exception
Network
Network Port RJ-45 (10/100 Base-T)
SDK and API Yes
Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Bonjour; Auto Registration
Interoperability ONVIF (Profile S & Profile G & Profile T & Profile M); CGI
User/Host 20 (Total bandwidth: 64 M)
Storage FTP;SFTP; Micro SD card (support max. 512 GB); NAS
Browser IE: IE11
Chrome
Firefox
Management Software Smart PSS Lite; DSS; DMSS; DoLynk Care
Mobile Client iOS;Android
Security Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; Syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
Certification
Certifications CE-LVD: EN 62368-1;
CE-EMC: Electromagnetc Compatbility Directve
2014/30/EU
Port
Audio Input 1 channel (RCA port)
Audio Output 1 channel (RCA port)
Alarm Input 1 channel in: wet contact, 5 mA 3–5 VDC
Alarm Output 1 channel out: wet contact, 300 mA 12 VDC
Power
Power Supply 12 VDC/PoE+ (802.3at)
Dual Power Backup When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart.
Power Consumption Basic: 4.3 W (12 VDC); 6.2 W (PoE)

Max. (H.265+WDR+ warm light+siren and light active deterrence + intelligence on): 11.8 W (12 VDC); 15.1 W (PoE)
Environment
Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity ≤95% (RH), non-condensing
Protection IP67
Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity ≤95% (RH), non-condensing
Structure
Casing Material Metal + plastic
Product Dimensions 288.4 mm × 94.4 mm × 84.7 mm (11.35″ × 3.72″× 3.33″)(L × W × H)
Net Weight 1.0 kg (2.20 lb)
Gross Weight 1.3 kg (2.87 lb)

Additional information

Lens

2.8mm, 3.6mm

Brand

Dahua
